Commissioning

Connecting the intermediate tube package to the power source

5.2 Connecting the intermediate tube package to the power source
Observe the operating instructions for the wire feed unit and for the power source!
The steps
• connect the intermediate tube package to the wire feed unit,
• connect the welding torch,
• connect the wire supply,
• shielding gas connection
and other steps are described in the operating instructions for the wire feed unit and the power
source.
5.2.1

OW ASM 2. DV PHOENIX PROGRESS K

8
NOTE
Figure 5-1
Item No.:099-OW0008-EWM01
