Appendix A Specifications

Physical Characteristics
Size: 125l x 31h x 35w (mm)
Total Mass: approx. 90 g (0.2 lb)
Power Source: Two AAA NiMH rechargeable batteries
Expected Battery Life with Normal Operation (connected via Bluetooth and
minimum 2,000 bar code scans): 8 hours
Operating Temp: 32 to 120°F (0 to 50°C)
Operating System Support:
• Windows Mobile 2003 (for Pocket PC 2003), Windows XP, Tablet XP
• Palm OS v5.2 and later
For information about using the CHS with Symbian OS, please visit:
www.socketcom.com/product/cordless.asp?Type=Scanner
2005 Sunrise Date Compliant
Scanning Characteristics
Bar Code Symbologies Decoded: Code 39, UPC/EAN/JAN, MSI, Code
128, Code 93, Codabar, I 2 of 5, D 2 of 5, RSS-14
Laser: Class 1 with Fuzzy Logic (Optional Class 2 with Fuzzy Logic)
Scan Angle: 46.5°
Laser Scanner Performance:
Scan Repetition Rate: 50 (± 3) scans/sec (bi-directional)
Decode Distances: 2.2 to 40+ inches depends on symbol size, symbology,
label media, W-N Ratio, scan angle
Bluetooth Characteristics
Protocol: Bluetooth 2.45 GHz ISM band frequency hopping
Antenna: Integrated
Radio Range: Up to 330 ft (100 m), depending on environment
Connection: Point-to-point Security: Encrypted link
RF Power: Class 1 radio; Typical Output: 14 dbm
Certification/Compliance
FCC: Part 15, Class B
C-TICK: s.182
ETS 300 328
60 | APPENDIX A: SPECIFICATIONS
4.9l x 1.2h x 1.4w (in.)
CE: EN55024:1998
Bluetooth 1.1 TELEC
ETS 300 826
