SATEL
Event log
 439 (INTEGRA 24 and INTEGRA 32), 5887 (INTEGRA 64) or 22527 (INTEGRA 128)
events.
 A separate memory space to store events required by the EN 50131 standard for Grade 2.
 Event log printing capability.
Users
 1 (INTEGRA 24), 4 (INTEGRA 32) or 8 (INTEGRA 64 and INTEGRA 128) master users
(administrators).
 16 (INTEGRA 24), 64 (INTEGRA 32), 192 (INTEGRA 64) or 240 (INTEGRA 128) users.
 Capability to assign to the user:
– a code,
– a proximity card (125 kHz passive transponder, which may be in the form of a card, tag,
etc.),
– DALLAS iButton (chip),
– keyfob.
 Several user types.
 Authority level determining the scope of access to the system.
Additional features
 Access control functions realized by means of additional modules.
 16 (INTEGRA 24), 28 (INTEGRA 32) or 64 (INTEGRA 64 and INTEGRA 128) timers
programmed by the installer to automatically:
– arm/disarm the partitions,
– control the outputs (switching the lights on/off, watering the garden, etc.).
 Partition timers (1 for each partition) to automatically arm/disarm the partitions.
Programming
 Local programming:
– keypad,
– computer with the DLOADX program installed, connected to the control panel RS-232
port.
 Remote programming:
– computer with the DLOADX program installed, communicating via the telephone
network or via the Ethernet network (optionally, if the ETHM-1 / ETHM-1 Plus module is
connected),
– internet browser (optionally, if the ETHM-1 / ETHM-1 Plus module is connected),
– mobile phone with suitable application installed (optionally, if the ETHM-1 / ETHM-1
Plus module is connected).
Mainboard
 RS-232 port (RJ type socket) to allow:
– local programming by means of a computer with the DLOADX program installed,
– local system administration by means of a computer with the GUARDX program
installed,
– remote programming using the DLOADX program via Ethernet (TCP/IP), if the ETHM-1
/ ETHM-1 Plus module is connected,
INTEGRA 5
