6.4.5 System Information

Press " " and " " in the main interface to select "System Information", and then press "ENT" to
view the parameters which is shown in figure 6.8.
The system information include "product model", "serial No.", "software version" and "certificate
version".

6.4.6 Faults

Press " " and " " in the main interface to review the fault history, and then press "ENT" to view
the sub-menu which is shown in figure 6.10.
There are 8 pieces of fault information in the record which is shown in figure 5.10; otherwise it will
display "No Fault!" Refer to section 6.4.2 for more detailed information.

6.4.7 Inverter control

Press " " and " " in the control interface, and then press "ENT" to view the sub-menu which is
shown in figure 6.11.
Refer to the table below for detailed information.
System Information
Part No . Cert . Area
Serial No .
Run Param
Soft Ver
Figure 6.8 System information
S y s t e m V e r
V e r s i o n 1
V e r s i o n 2
M C U V e r s i o n
Figure 6.9 System version
F a u l t
1 : A 0 0 5 G r i d u n d e r f r e q
1
2 : A 0 0 1 I n p u t u n d e r V o l t
3 :
Figure 6.10 Fault information
C o n t r o l M e n u
O n / O f f F a c t o r y
C l e a r
R e s t a r t
Figure 6.11 Control interface
52
: V 1 . 0 5
: V 1 . 0 5
: V 1 . 0 5
Display panel
