5 Appendix

5.1 Technical Data PM160

Specification
Wavelength Correction Range
Optical Power Measurement Range
Optical Power Resolution
Measurement Uncertainty
Power Linearity
Active Area Uniformity
Optical Filter
Max. Average Power Density
Sensor Aperture
Aperture Thread
Distance to Sensor
Sensor Thickness
Overall Dimensions
Weight
Built-in Display
Local Operation
Analog Measurement Ranges
AD Converter
Analog Bandwidth
Interface
Power Supply
Mounting Options
1
) Values in ( ) are with filter slided in.
2
) The appropriate range is chosen internally by the power meter to achieve the best accuracy.
3
) The battery is recharged through the USB connection.
All technical data are valid at 23 ± 5°C and 45 ± 15% rel. humidity (non condensing).
© 2018 Thorlabs
10 nW to 2 mW (200 mW)
+/- 3% @ 451 to 1000 nm
+/- 5% @ 400 to 450nm and 1001nm – 1100nm
None / (Reflective ND [OD1.5] with diffuser)
SM05 with included adapter
1.7 mm (4.2 mm with filter)
3.5 mm (6.0 mm with filter)
172.7 mm x 36.4 mm x 13.0 mm
Monochrome white OLED 24.0 mm (0.95") across diagonal, 96 x 64 px
USB 2.0, Bluetooth 2.1 (Class I, 10 dBm)
External: 5VDC via USB
Internal: LiPo+ 380 mAh
#8-32 and M4 tap combined, 3 positions
PM160
400 to 1100 nm
1
100 pW (10 nW) )
± 1%
± 1%
1
1 W/cm² (20 W/cm²) )
Ø 9.5 mm
60 g
4 push buttons
2
500 nA, 50 µA, 5 mA )
24 bit
10 Hz
3
