PM160(T)
4.1.2.5 PM160 GUI (Windows® OS)
Toolbars
The GUI has 4 toolbars, which can be enabled independently each from the
other:
View Switch between Needle View and Statistics View
Configure Unit
Wavelength Edit the operating wavelength (350...1100 nm)
Autoscale
Status Battery
Connect
Date / Time Shows actual date and time
Drop-down menus
"Device"
"Toolbars"
"Options"
"Help"
24
Select between Power [W], Power [dBm] and Current [A]
Switch between automatic and manual measurement scale set-
ting
Shows battery status
Shows connection status (USB or bluetooth)
Open Device...
Close Device
Device Information...
Close
The toolbars as described above can be enabled or disabled.
Select the language (English or German)
Displays detailed information about the application software.
Opens dialog to select a device from a list of
available devices
Disconnect the active device
Displays detailed information about the con-
nected device
Exits the application
