Planning the Installation

Planning the Installation
• Careful planning is required to insure an easy installation and proper operation of the equipment.
• Prior to beginning the installation, read the installation instructions that apply to your equipment.
This will save time and help avoid confusion.
Important: Due to the complexity of the equipment, make certain you are installing it properly as you
go.
Note: Different cage systems require different installation procedures for installing Power
Units, Troughs, and some Hangers. Be careful to refer to the appropriate section when
installing this equipment. The rest of the installation instructions for the different cage
systems are the same, except where noted.

Power Unit Requirements

Use the chart below to determine the required number of Power Units for each ULTRAFLO
your installation. The chart applies to layer and brood-grow cage styles.
Cage Row Length
for 60 Hz. Systems
(230 volts at Power Units)
Up to 120' (36 m)
121' (37 m) to 448' (137 m)
449' (137 m) to 505' (154 m)
over 505'(154 m)
Note: 208 volt power will require a 20% reduction in line length recommendations.

Hanger Requirements

Refer to the ULTRAFLO
for your installation. The ULTRAFLO

Additional Manuals

Refer to the following manuals as required for related equipment installation instructions.
• Model 55, 75, 90, & HMC FLEX-AUGER Fill System Manual MA1000
• Model 108 FLEX-AUGER Fill System Manual
• Model 90, 108, & Dual 90 Feed Screener Manual
• Feeder and Fill System Maintenance Schedule
• ULTRAFLO
• Dead End Fill System Manual
• 3 & 4 Output Control Instructions
Note: Some of the instructions listed above are available in various languages. Contact your
CHORE-TIME Distributor for additional manuals.
6
ULTRAFLO
(230 volts at Power Units)
Up to 96' (29 m)
97' (30 m) to 358' (109 m)
359' (109 m) to 404' (123 m)
404' (123 m) to 600' (183 m)
®
Hanger Chart on page 10 to help determine which Hangers are required
®
®
Loop Fill System Manual
Cage Feeding Systems for Brood Grow & Layer Installations
®
Cage Row Length
for 50 Hz. Systems
Hanger Chart also specifies the distance between Hangers.
®
Number of Power
Units Required
1
2
3
4
MA1032
MC1033
MC821
MC1191
MC1190
MC832
loop in
MC656P
