Part Numbers

Power Unit and Driver Assembly Part Number

10
4
13
14
Key Description
1 Pinion Assembly
2 10-24 Stamped Nut
3 Auger Brace
4 10-24 Hex Head Screw
5 Gearhead Assembly
6 Vent Plug
7 Magnetic Pipe Plug
8 Drive Unit Base
9 #10x1/2" Self-Drilling Screw
10 Drive Unit Cover
11 5/16-18x3/4 Hex Head Screw 2046
12 Drive Gear Hub
13 MULTIFLO Drive Gear
14 5/16-18x7/8 Cap Screw
15 Base Connector Weldment
34
ULTRAFLO
23
2
3
1
9
11
12
18
15
Part No.
See Chart
1560
24674
4416-3
See Chart
3523
30160
8207
3037
8208
8213
54383
6850-1
9636
Cage Feeding Systems for Brood Grow & Layer Installations
®
22
6
7
8
19
20
MC656-67 8/95
16
Key Description
16 1/4-20 Locknut
17 Dowel Pin
18 Wear Shoe
19 1/4-20x1/2" Hex Head Screw
20 End Connector Weldment
21 Motor
22* S-Hook
23* Chain
-- Danger Decal
* Not included in the Power Unit/Driver
Assembly
** Gearhead & Driver Assembly Part Numbers
include items #2 through#20.
21
5
17
Part No.
1269
8699
8210
1487
9634
See Chart
723
1302
2527-9
