Let's Go Aero BLACK BOX Product Manual

Slide-out enclosed cargo carrier system
Hide thumbs Also See for BLACK BOX:

Advertisement

Quick Links

Download this manual
Installation & Safe Use Operation Highlights
Rated for 300 lbs of cargo payload. 160 lbs empty weight.
Class II minimum tow rating required; Class III recommended.
BLACK BOX SYSTEM - ASSEMBLY, INSTALLATION, AND OPERATION INSTRUCTIONS:
Description
Parts & Tools List ...............................................................................................
Installation ..........................................................................................................
Open & Closing Operation .................................................................................
Slide-Out Operation ...........................................................................................
Warranty & Registration .....................................................................................
For More Information & Accessories, Visit our Website - www.LetsGoAero.com
For Technical Support & Product Questions Contact Us at 877-464-2376 or 719- 630-3800
BBOXManual-031819Rev
PRODUCT MANUAL
Fits 2" size receiver hitches.
READ THIS MANUAL THOROUGHLY.
BE SURE TO READ ALL WARNINGS BEFORE OPERATION.
Email: SUPPORT@LETSGOAERO.COM
Slide-Out Enclosed Cargo Carrier System
PAGE 1 OF 21
BLACK BOX
Set Item Product
Page
2
3
19
20
21

Advertisement

loading
Need help?

Need help?

Do you have a question about the BLACK BOX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Let's Go Aero BLACK BOX

Summary of Contents for Let's Go Aero BLACK BOX

  • Page 1 Fits 2” size receiver hitches. Rated for 300 lbs of cargo payload. 160 lbs empty weight. Class II minimum tow rating required; Class III recommended. BLACK BOX SYSTEM - ASSEMBLY, INSTALLATION, AND OPERATION INSTRUCTIONS: Description Page Parts & Tools List ....................
  • Page 2 6mm NYLON NUT FEMALE TUBES 6mm WASHER FRAME ANGLES REFLECTOR STRIPS HAT BRACKETS M8 CARRIAGE BOLTS M8 WASHERS AERFOIL LID (Black Box Cover) M8 NUTS QTY. DESCRIPTION REFLECTOR CAPS AERFOIL COVER SAFETY CABLE BULKHEAD BULK HEAD WITH HANDLE RACK & SIDE PANEL 1/4-20 JOINT SOCKET HEAD BOLT QTY.
  • Page 3 STEP 1 Compress one Spring Nut [G] within the FlatPipe Spine [A] end as shown. The [Figure 1] Spring Nut may be installed between either the first or the second mounting hole (user choice) [Figure 1]. NOTE: The FlatPipe Spine [A] end (called the “Shank”) contains two (2) mounting holes.
  • Page 4 STEP 3 Slide one (1) Rubber Bumper [K] onto [Figure 5] [Figure 6] each Flat Pipe Spine [A] tube (total 2). Push the Rubber Bumpers along the tubes until they sit flush against the frame of the FlatPipe Spine [Figure 5 & Using the provided water-proof Wax Block [J], rub along all four sides of each Spine tube to completely “coat”...
  • Page 5 STEP 6 Slide the 5/8 Plastic Bushing [F] onto the Hand-Tighten Silent Hitch Pin [D]. In the same manor as Step 2, insert and thread the Hand-Tighten Silent Hitch Pin [D] with the Plastic Bushing [F] through the Flat Pipe [A], Female Tubes [K] and internal Spring Nut [G] [Figure 10].
  • Page 6 STEP 9 Set the remaining Frame Angle [L] onto of Female [Figure 13] Tubes [K] as shown. This Frame Angle [L] is positioned closer to the vehicle than the Frame Angle from the last step. NOTE: This Frame Angle [L] is “mirrored” and positioned with the shorter end facing towards the vehicle as shown.
  • Page 7 STEP 11 Adjust the distance between the Frame Angles [L] so [Figure 15] the Frame Bars [EE] are approximately 18in apart. Lay the four (4) U-Tubes [U] on top of the Frame Bars [EE] [Figure 15]. The holes in the Frame Bars [EE] should line-up and match with the holes in the bottom of the U-Tube [U].
  • Page 8 STEP 13 TOOLS: 7/16” WRENCH & 5/32 HEX KEY Lay the final Floor Panel [S] in the center of [Figure 17] the carrier on top of the U-Tubes [U] [Figure 17]. From the underside of the carrier, secure the center Floor Panel [S] to the Floor Panels from Step 12 using six (6) 8mm x 20mm Button Head Bolts [X], twelve (12) 6mm Washers [Y], and six (6) 6mm Nylock Nuts...
  • Page 9 STEP 14 TOOLS: 5/32 HEX KEY Using the middle two (2) U-Tubes [Figure 19] [U] only, insert one (1) Pin Nut [CC] through each hole at the top of the U-Tubes. [Figure 19] NOTE: The “slot end” illustrates the Pin Nuts’ [CC] internal thread Large Hole direction.
  • Page 10 [Figure 24, [Figure 25] [Figure 26] STEP 16 TOOL: 1/2” WRENCH & 3/16 HEX KEY, ???????? Before] With the Side Rails [T] in place. Un-bolt and remove the four (f) 8mm x 70mm Button Head Bolts [W] at each end of the rack floor allowing the bottom lip of End Panels [KK] &...
  • Page 11 STEP 18 Insert Plugs [HH] into the large holes of the Side Rails at each corner of the carrier (total 4) [Figure 29]. [Figure 29] STEP 19 TOOLS: 1/2” WRENCH The BlackBox cargo carrier enjoys between 6in-12in of installed clearance from the vehicle and between 25in- 32in of clearance from the vehicle when slid out.
  • Page 12 STEP 20 From underneath the carrier, connect the quick-link end [Figure 32] UNDERNEATH CARRIER VIEW of the Safety Cable [R] to the hole in the frame of the Flat Pipe Spine [A] [Figure 32]. NOTE: The Safety Cable [R] can be secured in two (2) 1st Position positions.
  • Page 13 STEP 23 TOOLS: 7MM WRENCH & PHILLIPS HEAD SCREW DRIVER Remove the Washer and Nut supplied on the back side of the remaining LED Light [NN]. On the drivers side of the vehicle, mount the LED Light [NN] with two License Plate Brackets [PP] on either side of the LED Mount Bracket [QQ] using the supplied Phillips Screw on the LED Light.
  • Page 14 STEP 26 Remove backing and apply Reflector Strips [UU] to the outer U-Tubes [U] on the rear of the carrier as shown [Figure 38]. Install four (4) 1in Black End Caps [DD] into the open ends of the Frame Bars [EE] [Figure 38].
  • Page 15 STEP 28 TOOL: 5/32” HEX WRENCH NOTE: This step will be easiest if someone assists you. Form the AerFoil Cover [VV] around the Bulk Heads [WW & XX] inserting the edges of Bulk Heads into groove of cover as you go. Attach the remaining two corners with pre-installed Pin Nuts [ZZ] and Joint Connector Bolts [YY] using the same method used in STEP 27 [Figure 40].
  • Page 16 STEP 30 TOOLS: 7/16” WRENCHES NOTE: This step will be easiest if someone assists you. CAREFULLY, pivot the lid open towards the drivers side Hinge until the Hinges on the drivers side of the box align [Figure 43]. Using one (1) 3.5in x 1/4in [AAA] Bolt and one (1) 1/4in...
  • Page 17 STEP 31 TOOL: 5/16IN SOCKET Carefully, open the BlackBox lid. Starting from [Figure 48] the drivers side edge of the carrier (closest to the hinges), measure 13.25in along each side of the carrier tray edge. Mark these locations. Place the closest edge of each Lift Plate 13.25in [EEE] at the 13.25in mark with the top of the...
  • Page 18 STEP 31 TOOL: FLAT HEAD SCREW DRIVER Snap the Gas Shocks [Figure 54] [Figure 53] [GGG] onto the ball studs [FFF] of both Lift Arms NOTE: The thicker portion [GGG] of the Gas Shock Ball Stud must be installed onto the [FFF] side of the Lift Arm that is attached to the Lift...
  • Page 19 OPTIONAL TIP! TOOL: BLACK WATER-PROOF SILICONE CAULK For a complete weather seal, [Figure 57] it is recommended to caulk all gaps and edges with a black Silicone Water-proof Caulk [Figure 57]. OPERATION: Opening & Closing Always operate the BlackBox lid from the [Figure 58] passenger side of the vehicle.
  • Page 20 OPERATION: Opening & Closing [Figure 59] Slide-out: Remove the Retainer Clip and Hand-Tighten Pin and set aside [Figure 59]. Standing on the side of the carrier that is furthest away from the vehicle, gripping from the underside of the carrier, pull the carrier horizontally away from the vehicle untill the Safety Cable is fully extended. Slide-in: Standing on the side of the carrier that is furthest away from the vehicle, gripping from metal tray, push the carrier back towards the vehicle until the holes for the Hand-Tighten Pin re-align.

  • Page 21: One-Year Limited Warranty

    ONE YEAR LIMITED WARRANTY We warrant this Let’s Go Aero brand product during the time the original retail purchaser owns it. This warranty terminates if a purchaser transfers the product to any other person. Let’s Go Aero warrants this product to be free from defect in material and workmanship for one year (retain your sales receipt for your records).
