Nelson Accessory Adapter Kit for Roof and Overhead Fly Rod Accessories (not included).
Rated for 50 lbs on Flyrod Adapter Cradles only (25 lbs per Adapter Cradle). Increases the
overall V-Wing Capacity to 120 lbs with included Tie-off Kit.
NOTICE: All Manual information is subject to change without notice. Revised editions
will be available for free download at LetsGoAero.com. Manual information is considered
factual until made obsolete by a revised version.
Follow this QR-Code or visit
LetsGoAero.com/manuals to check for an updated version:
PARTS
QTY. DESCRIPTION
A
2
FLYROD CRADLES
B
2
TIE-OFF PLATE
C
2
STAR NUT
D
2
1/4-20 BOLT
E
2
SUSPENSION CABLE
F
2
WEBBING STRAP
G
2
S-HOOK WITH CAM BUCKLE
NOTE: This manual assumes you have already completed assembly of your original Nelson model carrier.

: Preparation

STEP 1

Remove the End Caps located on the top of each Nelson Wing
Support Arm
Copyright© 2021, Lets Go Aero, Inc., All rights reserved.
Adapter kit to install flyr rod, roof bar,overhead Fly Rod
accessories on Nelson Multi-Sport Carrier (not included)
Page 1 of 5
Fly Rod Adapter Kit
Part No. B02028
END CAP
NELSON WING
SUPPORT ARM
Revision Date: 06/15/21
[Fg. 1]

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fly Rod Adapter Kit and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Let's Go Aero Fly Rod Adapter Kit

Summary of Contents for Let's Go Aero Fly Rod Adapter Kit

  • Page 1 Fly Rod Adapter Kit Adapter kit to install flyr rod, roof bar,overhead Fly Rod accessories on Nelson Multi-Sport Carrier (not included) Part No. B02028 Nelson Accessory Adapter Kit for Roof and Overhead Fly Rod Accessories (not included). Rated for 50 lbs on Flyrod Adapter Cradles only (25 lbs per Adapter Cradle). Increases the overall V-Wing Capacity to 120 lbs with included Tie-off Kit.
  • Page 2 STEP 2 Slide one (1) Fly Rod Adapter [A] onto each Wing Support Arm [Fg. 2] and tighten the adjustment knob until snug [Fg. 2]. TIP: The Fly Rod Adapters can be placed facing in any direction and safely carry Fly Rod accessories, however it is recommended that Fly Rod Adapters are installed so that they mirror each other (see figures 3, 4 &...
  • Page 3 STEP 5 Once both Tie-off assemblies are attached. [Fg. 9] Remove ONE Tie-off Plate [B] by unbolting the 1/4-20 Bolt [D]. The Star Nut [C] will remain in place for future use. [Fg. 9] STEP 6 Loosen the Ring Pins (refer to your Nelson Manual for more information [Fg.
  • Page 4 STEP 8 With the Tie-off Plate [B] fully seated, re-insert and tighten the 1/4-20 Bolt [D]. [Fg. 14] [Fg. 14] STEP 9 Re-tighten the Ring Pins. [Fg. 15] [Fg. 15] RING PIN STEP 10 Loop the looped end of the each Webbing Strap [F] around the end of [Fg.
  • Page 5 WEIGH LIMITATIONS EXPLAINED The Fly Rod Cradles have a 25 lbs weight limit each for a combined 50 lbs. Accessories attached to the Fly Rod Cradles may not exceed 50 lbs. [Fg. 20] The Tie-offs included in this kit increase the overall weight limit of the V-Wing to a combined 120 lbs. EXAMPLE: Users MAY carry a 50 lbs Rod Vault attached to the Fly Rod Cradles [A] and also carry two bikes at 35 lbs each on the V-Wing.
