Operating and installation instructions
SmartLine induction wok
To avoid the risk of accidents or damage to the appliance it is essential
to read these instructions before it is installed and used for the first time.
en-GB
M.-Nr. 10 803 060

Advertisement

Table of Contents
loading

  Also See for Miele CS 7611

Miele SmartLine Series Operating And Installation Instructions
Miele SmartLine Series Operating And Installation Instructions 72 pages
Miele SmartLine CS 7611 Operating And Installation Instructions
Miele SmartLine CS 7611 Operating And Installation Instructions 72 pages
Miele SmartLine CS 7611 Operating And Installation Instructions
Miele SmartLine CS 7611 Operating And Installation Instructions 68 pages

  Related Manuals for Miele CS 7611

  Summary of Contents for Miele CS 7611

  • Page 1 Operating and installation instructions SmartLine induction wok To avoid the risk of accidents or damage to the appliance it is essential to read these instructions before it is installed and used for the first time. en-GB M.-Nr. 10 803 060...

  • Page 2: Table Of Contents

    Contents Warning and Safety instructions................ 4 Caring for the environment ................ 14 Guide to the appliance .................. 15 Wok ........................15 Controls / Indicators....................16 Cooking zones....................... 17 Accessories supplied .................... 18 Before using for the first time ................ 19 Cleaning the SmartLine element for the first time..........
  • Page 3 Contents Cleaning and care .................... 38 Problem solving guide .................. 40 Optional accessories .................. 44 Safety instructions for installation.............. 45 Safety distances .................... 46 Installation notes .................... 50 Onset installation....................50 Installing several SmartLine elements ..............52 Combination with a downdraft extractor............... 52 Induction wok next to the downdraft extractor .............

  • Page 4: Warning And Safety Instructions

    They contain important notes on installation, safety, use and maintenance. Miele cannot be held liable for damage caused by non-compliance with these instructions. Keep these instructions in a safe place and ensure that new users...
  • Page 5 Warning and Safety instructions Correct application  This wok is designed for domestic use and for use in similar envir- onments.  This wok is not intended for outdoor use.  This wok is intended for domestic use only to cook food and keep it warm.
  • Page 6 Warning and Safety instructions Safety with children  Children under 8 years of age must be kept away from the wok unless they are constantly supervised.  Children 8 years and older may only use the wok unsupervised if they have been shown how to use it safely and recognise and under- stand the consequences of incorrect operation.
  • Page 7 Unauthorised installation, maintenance and repairs can cause considerable danger for the user. Installation, maintenance and re- pairs must only be carried out by a Miele authorised technician.  A damaged wok can be dangerous. Check it for visible signs of damage.
  • Page 8 Miele authorised service technician. Otherwise the war- ranty is invalidated.  Miele can only guarantee the safety of the appliance when genu- ine original Miele replacement parts are used. Faulty components must only be replaced by Miele spare parts.
  • Page 9 Warning and Safety instructions  In areas which may be subject to infestation by cockroaches or other vermin, pay particular attention to keeping the appliance and its surroundings clean at all times. Any damage caused by cock- roaches or other vermin will not be covered by the warranty.
  • Page 10 Warning and Safety instructions Correct use  The wok gets hot when in use and remains hot for some time after being switched off. The risk of burning is present until the residual heat indicators have gone out.  Overheated fat and oil can ignite and catch fire. Never leave the wok unattended.
  • Page 11 Warning and Safety instructions  You could burn yourself on the hot wok. Protect your hands with heat-resistant pot holders or gloves when handling hot pots and pans. Do not let them get wet or damp, as this causes heat to trans- fer through the material more quickly with the risk of scalding or burning yourself.
  • Page 12 Warning and Safety instructions  Heat oil or fat for a maximum of one minute. Never use the Booster function to heat oil or fat.  For people fitted with a heart pacemaker: please note that the area immediately surrounding the wok is electromagnetically charged.
  • Page 13 Warning and Safety instructions Cleaning and care  Do not use a steam cleaning appliance to clean this wok. The steam could reach electrical components and cause a short cir- cuit.  If the wok is built in over a pyrolytic oven, the wok should not be used whilst the pyrolitic process is being carried out, as this could trigger the overheating protection mechanism on the wok (see relev- ant section).

  • Page 14: Caring For The Environment

    / recycling centre for electrical and electronic ap- pliances, or contact your dealer or Miele for advice. You are also respons- ible (by law, depending on country) for deleting any personal data that may be stored on the appliance being disposed of.

  • Page 15: Guide To The Appliance

    Guide to the appliance a Wok basin b Controls / Indicators...

  • Page 16: Controls / Indicators

    Guide to the appliance Controls / Indicators Sensor controls a Switching the wok on and off b Stop & Go c Wipe protection d Activating/deactivating the keeping warm function e Numerical keybank For setting power levels/minute minder and switch-off times f Automatic switch-off g Minute minder Indicator lights h Automatic switch-off...

  • Page 17: Cooking Zones

    Guide to the appliance Cooking zones Wok basin Ø in cm* Rating in watts for 230 V** 30.0 Normal 2400 TwinBooster, level 1 2650 TwinBooster, level 2 3000...

  • Page 18: Accessories Supplied

    Guide to the appliance Accessories supplied The accessories supplied with your ap- pliance as well as a range of optional ones are available to order from Miele (see “Optional accessories”). Wok pan CSWP 1450...

  • Page 19: Before Using For The First Time

    Before using for the first time  Please stick the extra data plate for Switching on the SmartLine the appliance supplied with this doc- element for the first time umentation in the space provided in The metal components have a protect- the “After sales service”...

  • Page 20: Induction

    Induction How it works  When the wok is switched on either deliberately or by mistake, or An induction coil is located under the when there is residual heat present, wok basin. When the wok is switched there is the risk of any metal items on, this coil creates a magnetic field left on the wok heating up.
  • Page 21 Induction Noises Pans The following noises might occur in the Only use the wok pan supplied with wok pan when the induction wok is in the appliance for cooking food. operation: This wok pan is designed specifically for this appliance. On the higher power settings, it might buzz.

  • Page 22: Operation

    Operation Settings Malfunction due to dirty and/or covered sensor controls. Cooking process Setting If the sensor controls are dirty or range covered this could cause them to fail Keeping food warm, melting to react, to activate a function or chocolate even to switch the appliance off Warming food up automatically (see “Safety switch-...

  • Page 23: Switching On The Wok

    Operation Residual heat indicator  Fire hazard. Do not leave the wok unattended If the SmartLine element is still hot, the whilst it is being used. residual heat indicator will light up after Please note that the heating up time it has been switched off.

  • Page 24: Auto Heat-Up

    Operation Auto heat-up Continued cook- Heat-up time ing setting [min : sec] When Auto heat-up has been activated, the cooking zone switches on automat- approx. 0 : 15 ically at the highest setting and then approx. 0 : 15 switches to the continued cooking set- ting which you have previously selec- approx.

  • Page 25: Booster

    Operation Activating TwinBooster, level 1 Booster  Place the wok pan in position. The wok is equipped with a Twin- Booster.  Select a power level if necessary. When activated, the power is boosted  Touch the B sensor control. for a maximum of 15 minutes. The indicator ...

  • Page 26: Keeping Warm

    Operation Activating/deactivating the keeping Keeping warm warm function This function is for keeping food warm  Touch the  sensor control. which has just been cooked and is still hot. It is not for reheating food that has gone cold. The maximum duration for keeping food warm is 2 hours.

  • Page 27: Timer

    Timer The SmartLine element has to be The functions can be used at the same switched on if you wish to use the timer. time. The shortest time is always dis- played and the  sensor control A duration of between 1 minute (:) and 9 hours 59 minutes (:) can be (minute minder) or the indicator light for set.

  • Page 28: Switching Off A Cooking Zone Automatically

    Timer To change a switch-off time Switching off a cooking zone automatically  Touch the  sensor repeatedly until the indicator light for the zone you re- You can set a time after which the quire flashes. cooking zone will switch off automatic- ally.

  • Page 29: Additional Functions

    Additional functions Stop & Go Recall The set power level is reduced to 1 If the SmartLine element is accidentally when the Stop & Go function is activ- switched off during use, you can use ated. this function to restore all the settings. The power levels and timer settings The SmartLine element must be cannot be changed;...

  • Page 30: Wipe Protection

    Additional functions Wipe protection Displaying the SmartLine ele- ment data You can lock the SmartLine element The model designation and software sensor controls for 20 seconds in or- version of the SmartLine element can der to remove soiling, for example. be displayed.

  • Page 31: Safety Features

    Safety features The safety lock is activated when the System lock / Safety lock SmartLine element is switched on. The lock function is deactivated if When the safety lock is activated, the there is a break in the mains supply. element can be operated only under certain conditions: Your SmartLine element is equipped...
  • Page 32 Safety features Activating the safety lock  Touch and hold the  and  sensors at the same time for 6 seconds. The time will count down in the timer display.  will appear once the time has elapsed. The safety lock is activ- ated.

  • Page 33: Safety Switch-Off

    Safety features Safety switch-off Power level* Maximum operating time [h:min] Safety switch-off if the sensors are Safety setting covered Your SmartLine element will turn off 10:00 8:00 5:00 automatically if one or several of the sensor controls remain covered for 10:00 7:00 4:00...

  • Page 34: Overheating Protection

    If, despite removing the cause, the – The set power level will be reduced. overheating protection mechanism trig- gers again, contact Miele. – The cooking zone switches off auto- matically.  flashes in the timer dis- play alternating with .

  • Page 35: Programming

    Programming You can adapt the programming of the Saving the settings SmartLine element to your personal  While the programme is showing in needs. Several settings can be altered the display (e.g. :) touch the  in succession. sensor control until the indicators go out.
  • Page 36 Programming Settings Programme Code P:01 Demonstration mode C:00 Demonstration mode off C:01 Demonstration mode on P:03 Factory setting C:00 Do not restore standard settings C:01 Restore standard settings P:04 Number of power levels C:00 9 power levels C:01 17 power levels P:06 Keypad tone when a sensor is C:00...
  • Page 37 Programming Settings Programme Code P:15 Permanent pan recognition C:00 Not active C:01 Active Unlisted programmes are not assigned. The factory setting is shown in bold. After the SmartLine element has been switched on  appears in the timer display for a few seconds.

  • Page 38: Cleaning And Care

    Cleaning and care  Allow the SmartLine element to cool Danger of burning. down before cleaning. The cooking zone must be switched off. The wok must have cooled  Clean the SmartLine element and ac- down. cessories after each use. ...
  • Page 39  Afterwards, clean the ceramic surface  Then clean the ceramic glass surface in its cooled state, as described with the Miele ceramic and stainless above. steel hob cleaner (see “Optional ac- cessories”) or with a commercially...

  • Page 40: Problem Solving Guide

    There is no power to the SmartLine element. cannot be switched on.  Check whether the mains fuse has tripped. Con- tact an electrician or Miele Service (for the min- imum fuse rating, see data plate). There may be a technical fault.
  • Page 41 Problem solving guide Problem Cause and remedy The SmartLine element One or more of the sensor controls are covered, e.g. has switched off auto- by finger contact, food boiling over or an object. matically. When the ele-  Clean off any dirt or remove the object (see ment is switched back “Safety switch-off”).
  • Page 42  Interrupt the power supply to the SmartLine ele- ment for approx. 1 minute.  If the problem persists after power has been re- stored, please contact Miele Service.  flashes alternately The SmartLine element is connected incorrectly. with  in the timer dis- ...
  • Page 43  and other numbers There is a fault in the electronic module.  Interrupt the power supply to the SmartLine ele- ment for approx. 1 minute.  If the problem persists after power has been re- stored, please contact Miele Service.

  • Page 44: Optional Accessories

    250 ml Miele appliances. These products can be ordered through the Miele Webshop. They can also be ordered from Miele Removes heavy soiling, limescale de- (see end of this booklet for contact de- posits and aluminium residues tails) or from your Miele dealer.

  • Page 45: Safety Instructions For Installation

    Safety instructions for installation Fit the wall units and cooker hood before fitting the SmartLine element to avoid damaging it.  The veneer or laminate coatings of worktops (or adjacent kitchen units) must be treated with 100 °C heat-resistant adhesive which will not dissolve or distort.

  • Page 46: Safety Distances

    Safety distances Safety distance above the SmartLine element The safety distance specified by the manufacturer of the cooker hood must be maintained between the SmartLine element and the cooker hood above it. If combustible objects are installed above the SmartLine element (e.g. cab- inets, utensil rail, etc.), a minimum safety distance of 600 mm must be maintained.
  • Page 47 Safety distances Safety distances to the sides and back of the hob The SmartLine element should prefer- ably be installed with plenty of space on the right and left. The minimum distance  specified be- low must be observed between the rear of the SmartLine element and a tall unit Not allowed or room wall.
  • Page 48 Safety distances Minimum safety distances un- Interim shelf derneath the element It is not necessary to fit an interim shelf underneath the SmartLine element but To ensure proper ventilation of the one may be fitted if you wish. SmartLine element, a minimum clear- ance is required between the element Leave a gap of 10 mm at the back of and an oven, interim shelf, or drawer.
  • Page 49 Safety distances Safety distance when installing the appliance near a wall with additional niche cladding If a niche cladding is installed, a minimum safety distance must be maintained between the worktop cut-out and the cladding, since high temperatures can dam- age these materials.

  • Page 50: Installation Notes

    Installation notes Tiled worktop All dimensions are given in mm. Onset installation Sealing between the SmartLine Ele- ment and the worktop Grout lines  and the hatched area un- derneath the SmartLine element frame must be smooth and even. If they are not, the SmartLine element will not sit flush with the worktop and the sealing strip underneath the top part of the ap-...
  • Page 51 Installation notes The SmartLine element is Flush-fit installation – directly installed in a suitable cut-out Flush-fit installation is only possible in in a natural stone worktop, natural stone (granite, marble), solid wood and tiled worktops. For installa- – secured in a suitable cut-out in solid tion in worktops made of other materi- wood and tiled worktops with a als, please consult the relevant manu-...

  • Page 52: Installing Several Smartline Elements

    Installation notes Installing several SmartLine elements The gaps between the individual Smart- Line elements are sealed with a silicone sealant that is heat-resistant to at least 160 °C. With flush-fit installation, the gap between the SmartLine element(s) and the worktop must also be sealed with a silicone sealant that is heat-res- istant to at least 160 °C.

  • Page 53: Building-In Dimensions

    Building-in dimensions Onset installation a Front b Mains connection cable, L = 2000 mm...

  • Page 54: Flush-Fit Installation

    Building-in dimensions Flush-fit installation a Front b Mains connection cable, L = 2000 mm c Stepped cut-out (for detailed illustrations, see “Worktop cut-out for flush-fit in- stallation”) d 12 mm wooden frame (not supplied, for detailed illustrations, see “Worktop cut- out for flush-fit installation”)

  • Page 55: Worktop Cut-Out For Onset Installation

    Worktop cut-out for onset installation Information for calculating the cut-out The elements overlap the worktop by 10 mm. When installing several elements, a distance of 2 mm must be observed between the individual elements. Calculating cut-out dimension B 1 element = width of the element minus 10 mm on the right, minus 10 mm on the left Several elements = total width of the elements plus 2 mm distance between the elements, minus 10 mm on the right, minus 10 mm on the left.
  • Page 56 Worktop cut-out for onset installation Installation with a downdraft extractor Sample combinations Number x width [mm] Dimen- sion B Cooking Downdraft [mm] elements extractor 1 x 378 1 x 120 2 x 378 1 x 120 1 x 378 2 x 120 1224 1 x 620 3 x 378 2 x 120 1362 2 x 378 2 x 120 1604 1 x 620 4 x 378 2 x 120 1742 1 x 620 2 x 120...
  • Page 57 Worktop cut-out for onset installation Installation without a downdraft extractor Sample combinations Number x width [mm] Dimension B [mm] Cooking elements 1 x 378 2 x 378 1 x 378 1 x 620 3 x 378 1118 2 x 378 1360 1 x 620 4 x 378 1498...

  • Page 58: Worktop Cut-Out For Flush-Fit Installation

    Worktop cut-out for flush-fit installation Natural stone worktop Wooden worktop + 0.5  mm for CS 7611 Information for calculating the cut-out The elements overlap the worktop by 10 mm. When installing several elements, a distance of 2 mm must be observed between the individual elements.
  • Page 59 Worktop cut-out for flush-fit installation Installation with a downdraft extractor Sample combinations Number x width [mm] Dimen- Dimen- sion A sion B Cooking Downdraft [mm] [mm] elements extractor 1 x 378 1 x 120 2 x 378 1 x 120 1 x 378 2 x 120 1248 1224 1 x 620 3 x 378 2 x 120 1386 1362 2 x 378 2 x 120 1628 1604 1 x 620 4 x 378...
  • Page 60 Worktop cut-out for flush-fit installation Installation without a downdraft extractor Sample combina- Number x width Dimension A Dimension B tions [mm] [mm] [mm] Cooking elements 1 x 378 2 x 378 1 x 378 1004 1 x 620 3 x 378 1142 1118 2 x 378 1384 1360 1 x 620 4 x 378 1522 1498...

  • Page 61: Spacer Bars

    Spacer bars When installing several SmartLine elements, an additional spacer bar must be fit- ted in between the individual elements. The clips supplied with the spacer bars are only required for installing the CSDA. Installing 3 elements and 2 spacer bars Onset installation Flush-fit installation...

  • Page 62: Installation

     For wooden worktops, secure the wooden frames 5.5 mm below the upper edge of the worktop. For CS 7611, the wooden frame must be secured 7 mm under the upper edge of the worktop.  Position the spacer bars flush onto the upper edge of the cut-out or onto the lower step of the stepped cut-out.

  • Page 63: Installing The Smartline Element

    Installation Natural stone worktops Installing the SmartLine ele- ment You will need heavy-duty double-side tape (not supplied) to secure the  Stick the supplied sealing strip under spacer bars. the edge of the SmartLine element. Do not apply the sealing strip under tension.
  • Page 64 Installation Flush-fit installation  Connect the SmartLine element to the mains.  If required, connect the SmartLine element to the gas supply (see “Gas connection”).  Check that the SmartLine element works.  Seal the gaps between the individual elements and between the elements and the worktop with a silicone seal- ant that is heat-resistant to at least 160 °C.

  • Page 65: Electrical Connection

    Connection data gerous. Miele cannot be held liable for unauthorised work. The connection data is quoted on the Miele cannot be held liable for dam- data plate. Please ensure these match age or injury caused by unauthorised the household mains supply.
  • Page 66 These Safety fuses cables are available from the manufac-  Completely remove fuses turer or from the Miele Spare Parts De- partment. Automatic circuit breakers  Press the (red) button until the middle (black) button springs out.

  • Page 67: After Sales Service

    In the event of any faults which you cannot remedy yourself, please contact your Miele Dealer or Miele Service. Contact information for Miele Service can be found at the end of this document. Please note that telephone calls may be monitored and recorded for training pur- poses and that a call-out charge will be applied to service visits where the problem could have been resolved as described in this booklet.
