How to Install
6 6
Illustration 6.21 X8

6.3.3 Physical Dimensions

Enclosure
type
X1
X2
X3
X4
X5
X6
X7
X8
54
AHF005/010 Design Guide
490 mm (19.29 In)
Dimensions in mm
A (height) B (width)
245 190
350 230
460 330
490 330
747 370
778 370
909 468
911 468
MG.80.C4.02 - VLT
9 mm (0.35 In)

6.3.4 IP00 Dimensions

Enclosure
C (depth) Type
205 X1
248 X2
242 X3
333 X4
333 X5
400 X6
450 X7
550 X8
®
is a registered Danfoss trademark
468 mm (18.43 In)
443 mm (17.44 In)
412 mm (16.22 In)
Dimensions in mm
A (height) B (width)
332 188
435 230
594 378
624 378
737 418
767 418
897 468
898 468
C (depth)
197
214
239
333
332
415
437
490
