Managing The Bridge - 3Com LinkBuilder MSH User Manual

Managing The Bridge

The bridge can be managed using either the VT100 management
interface or remotely via SNMP using a suitable application, as
shown in
management facilities.
Figure 1-5 VT100 Management
To use the VT100 management interface:
Connect a VT100 terminal or VT100 terminal emulator directly to
the serial port on the display panel of the LinkBuilder MSH.
Use a VT100 terminal emulator over a network, via Telnet.
To manage the bridge, you must have a LinkBuilder MSH
Management Module (3C18500) with software version 2.1 or
later installed. If you do not have a Management Module
installed, contact your supplier.
Please refer to The LinkBuilder MSH Management Module
manuals for information on connecting VT100.
DUA1860-0AAA01
Figure 1-5. SNMP provides a subset of the VT100
Managing The Bridge 1-7
