The LinkBuilder MSH 4 Port Ethernet Bridge Module

The bridge module provides a bridge connection between the
three Ethernet busses of the MSH and an external port (the bridge
module's transceiver module), as shown in
bridge's connections are referred to as ports (1, 2, 3 and E).
Figure 1-2 The Network Segments
DUA1860-0AAA01
The LinkBuilder MSH 4 Port Ethernet Bridge Module
1
2
3
Figure 1-2. The
1-3
E
