1-6
C
1: I
HAPTER
NTRODUCTION
A Transceiver Module can be fitted to the bridge, providing its
fourth port, as shown in
Figure
1-4. A range of Modular
Transceivers are produced by 3Com, allowing you flexibility when
deciding on network connections and cabling:
3C12060 Female AUI Transceiver Module
3C12065 Fiber Transceiver Module (ST)
3C12064 Fan Out Transceiver Module
3C12066 Coaxial Transceiver Module
3C12060 LinkBuilder Bridge MicroModule
Your supplier will know of any other Transceiver Modules not
listed here.
Figure 1-4 The Transceiver Module
Instructions on how to fit a Transceiver Module are given in the
manual that accompanies it.
DUA1860-0AAA01
