Local And Remote Bridges

There are two main types of bridge, local and remote. The
LinkBuilder MSH 4 Port Ethernet Bridge Module is a local bridge.
Local bridges are used for bridging networks on the same site, as
shown in
Figure 1-6 Local Bridge
Remote bridges are used for bridging networks across large areas.
A remote bridge is often called a half bridge because each
network connects to half of the remote bridge. The remote
bridge halves are connected by a Wide Area Network (WAN) link,
as shown in
Figure 1-7 Remote Bridge
Both types of bridge have essentially the same operation and
functionality.
DUA1860-0AAA01
Figure 1-6.
Figure 1-7.
Bridging 1-9
