DIAGNOSTICS

If the system "machine+radio remote control" does not start, check if the problem is caused by
the radio remote control or the machine. Therefore, before carrying out any verification connect
the cable control unit: if the machine does not start, the problem lies with the machine itself.
If, on the other hand, the machine only starts when using the cable control unit, the problem
lies with the radio remote control. In this case, follow the diagnostic procedure related to the
transmitting unit and that related to the receiving unit if it is the case, and proceed as follows.
Before carrying out diagnostics it is recommended to replace the battery with a
charged one and ensure the efficiency of the starting keyswitch.
9.1

Transmitting unit diagnostics

When START is
activated, is the red LED
lit steadily and does the
buzzer sound?
Does the red LED blink
and does the buzzer
Does the green LED
CALL TECHNICAL
- 28 -
YES
NO
YES
sound?
NO
YES
blink?
NO
ASSISTANCE
STOP pushbutton or one
of the movement
actuators are activated:
disconnect it/them.
The battery is discharged:
replace it with a fully
YES
charged one. Does the
LED continue to blink and
the buzzer sounding?
NO
Carry out diagnostics
checks on the receiving
unit (see paragraph 9.2)
YES
Is the LED lit with a steady
light?
NO
Clean contacts in the bat-
YES
tery housing. Does the
LED continue to blink and
the buzzer sounding?
NO
