AUTEC DYNAMIC+P Series Instruction Manual For The Use And The Maintenance
Radio remote control; transmitting unit
Hide thumbs
Also See for DYNAMIC+P Series:
Related Manuals for AUTEC DYNAMIC+P Series
Summary of Contents for AUTEC DYNAMIC+P Series
- Page 1 LIUPJQ001_eng-00 Instruction Manual for the use and the maintenance of the Radio Remote Control Original instructions Part C: PJQ Transmitting Unit DYNAMIC+P SERIES...
- Page 3 It is also the responsibility of the Manufacturer and of the design professionals of the Machine on which the Autec Radio Remote Control is to be installed and used to be certain that the structure, condition, organization and markings of the Machine as installed at the facility is appropriate for and will allow for the safe and reliable use and control of the Machine through the Autec Radio Remote Control interface.
- Page 4 OR PROPERTY DAMAGE. Refer to this Manual and each of its Parts for further assistance or contact Autec. Autec is not responsible for and shall not be held liable for any installation of the Autec Radio Remote Control not performed by Autec or for any use of the Autec...
- Page 5 OFFICERS, MANAGERS AND SUPERVISORS, to be certain that the areas in which the Machine operated by or through the Autec Radio Remote Control is located and operates are clearly delineated and marked in accordance with all Autec warnings and instructions,...
- Page 6 LIUPJQ001_eng-00 AUTEC...
-
Page 7: Table Of Contents
10 Maintenance ......................37 11 Malfunction signalled by the Transmitting Unit ............. 37 11.1 Red LED and green LED ................... 37 11.2 2.8” display ....................... 39 11.3 Identifying the activated command ..............40 12 Decommissioning and disposal ................42 AUTEC LIUPJQ001_eng-00... -
Page 8: Information On The Use Of Instructions
(Part A) of the Manual provided with the Radio Remote Control. Structure of the Instruction Manual The Manual for the use and maintenance of Autec Radio Remote Controls consists in different parts, that altogether form the Manual; the Manual must be read carefully, understood and applied by the Radio Remote Control's Owner, User and by all those Persons that, for any reasons, may operate with the Radio Remote Control or with the Machine where it is installed. - Page 9 Receiving Unit. Usage and maintenance instruction as a whole are to be considered as an integral part both of the Autec Radio Remote Control and of the Machine, system, device or Machinery system where the Radio Remote Control is installed.
-
Page 10: Caption And Terminology
Caption and terminology Contact Autec if any of the instructions, symbols, warnings or images are not clear and understandable, or if you have doubts or questions. In this part of the Manual, the terms listed below have the same meaning explained in the... -
Page 11: To Whom The Instructions Are Addressed
Brief product presentation Series, Radio Remote Control and Unit The object of this part of the Manual is the PJQ (Model J6P) Transmitting Unit of an Autec Dynamic+P series' Radio Remote Control. Autec Dynamic+P series' Radio Remote Controls are designed to be used on Machines and provide a command interface to their command and control system, to be used from an appropriate distance and position. -
Page 12: Description Of The Transmitting Unit
When applying for technical service to Autec, its distributors, dealers and authorized service centres, the Radio Remote Control's serial number is required; you can find it on the identification plate on the Transmitting Unit and/or on the Receiving Unit. Description of the Transmitting Unit... -
Page 13: Technical Data
A Technical Data Sheet must always be kept together with this Manual: if you need to use the Technical Data Sheet for administrative purposes (tests, check, etc.), make a copy of it. The wiring of the Receiving Unit's outputs must always reflect the wiring indicated in the Technical Data Sheet. AUTEC LIUPJQ001_eng-00... -
Page 14: Plates
Model, Type and main Back side of the Transmitting Transmitting Unit technical data, Technical data plate Unit marking and possible Radio Remote Control marks Light and acoustic warning signals Light signals Red LED Green LED LEDs for Data Feedback function LIUPJQ001_eng-00 AUTEC... - Page 15 The green LED repeats the sequence: three blinks The Radio Remote Control is started and the Units and a pause. communicate via cable control. The red LED is off. The meaning of the green [B] and red [A] LED signals cannot be modified. AUTEC LIUPJQ001_eng-00...
-
Page 16: Acoustic Signals
Mechanical key The mechanical key makes it possible to power the Transmitting Unit. Inserting the mechanical key Do the following to insert the mechanical key: 1. Insert the mechanical key into its receptacle. 2. Turn the mechanical key clockwise. LIUPJQ001_eng-00 AUTEC... -
Page 17: Start Pushbutton
- Make sure that the working and usage conditions are safe. - Pull or turn the STOP pushbutton in the arrow direction (shown on the button) to unlock it. - Start the Radio Remote Control following the procedure described in paragraph 8.8). AUTEC LIUPJQ001_eng-00... -
Page 18: Pushbuttons For Display/Led
2.8” display 4.3” display Red LED Green LED LEDs for Data Feedback function Display Keys The pushbuttons [E] on the Transmitting Unit are used to interact with the display [D] and the LEDs for Data Feedback function [C]. LIUPJQ001_eng-00 AUTEC... -
Page 19: Command Meaning
This switch increases (rpm +) or decreases (rpm -) the number of revolutions of a Machine's engine. Symbol Meaning This symbol identifies the command that increases the number of revolutions of a Machine's engine. This symbol identifies the command that decreases the number of revolutions of a Machine's engine. AUTEC LIUPJQ001_eng-00... - Page 20 Depending on the configuration, this symbol indicates: - the reduced speed of the Machine movements or - the decrease of speed of the Machine movements. If this symbol is present, it indicates that the speed of the Machine movements is further reduced. LIUPJQ001_eng-00 AUTEC...
-
Page 21: Low Power Function
Instruction Manual). This function aims at: - Making it easier to work with several Radio Remote Control in the same working environment (i.e.: many working Machines in the same working area) - Extending the battery run-time. AUTEC LIUPJQ001_eng-00... -
Page 22: Battery
This function is established by the Machine Manufacturer (see Technical Data Sheet). Battery The Dynamic+P series' Transmitting Units can only be powered by Autec rechargeable batteries. For any warnings and instructions regarding the battery, see "Part E" in the Instruction Manual. -
Page 23: Starting Up The Radio Remote Control
In this case, to keep this signal active, hold the START pushbutton pressed until the Transmitting Unit automatically switches off (otherwise the signal will be interrupted). If none of the monitored commands is active, the Radio Remote Control starts. AUTEC LIUPJQ001_eng-00... -
Page 24: How To Take Control Of The Receiving Unit In A Take & Release Radio Remote Control
Receiving Unit's seven-segment display appears "---F". Autec can set the RELEASE command to be activated in a different way than the above mentioned ones, only upon request by either the Machine Manufacturer or the Installer: the User must be properly trained in the matter. -
Page 25: Command Activation
The Transmitting Unit automatically switches off after 3.5 minutes after the onset of the signal. It is necessary to bring the Machine to a safe state and replace the battery with a charged one (see paragraph 8.7). AUTEC LIUPJQ001_eng-00... -
Page 26: Switching Off The Transmitting Unit
Technical Data Sheet (Automatic Switch Off). Setting or removal of the automatic switch off time (Automatic Switch Off) is done by Autec and decided by the Machine Manufacturer, according to his risk assessment and to the operation and functions he needs on the Machine. -
Page 27: Cable Control
The cable control connects the Transmitting Unit to the Receiving Unit through a cable that replaces the radio link. The cable shall be plugged in the suitable connectors, one on the Transmitting Unit and the other on the Receiving Unit (or placed where established by the Machine Manufacturer). AUTEC LIUPJQ001_eng-00... - Page 28 Receiving Unit via the cable control. The battery is not, in any case, recharged through the cable control: it can only be recharged through its appropriate battery charger provided together with the system. LIUPJQ001_eng-00 AUTEC...
-
Page 29: Back-Up Unit
BACK-UP UNIT, so that all the Units belonging to the Radio Remote Control will show the same serial number. Autec cannot be held responsible if the serial number of the Transmitting Unit to be replaced has not been marked on BACK-UP UNIT. -
Page 30: Instructions For The User
However, instructions given in the following paragraphs do not replace nor complete the instructions that must be provided to the User by the Manufacturer of the Machine where an Autec Radio Remote Control (to which the PJQ Transmitting Unit belongs) is installed. Usage restrictions... - Page 31 - Make sure that the Transmitting Unit and the Receiving Unit are whole and work perfectly. - Make sure that the Machine reacts correctly to the commands activated by the Autec Radio Remote Control. - Not perform any operation if the tests mentioned in the previous two points did not give positive results.
-
Page 32: Belt Or Harness
The Unit always comes with a waist belt or a shoulder harness: the User must mount the belt or the harness on the Transmitting Unit and use it as described in paragraph 9.3.1 or 9.3.2. Replace the belt or harness if it is damaged or worn. 9.3.1 Waist belt Assembly LIUPJQ001_eng-00 AUTEC... - Page 33 If the Transmitting Unit and the belt are used in a different way from the one described in the above mentioned figure, this constitutes improper use and may lead to damage to the Transmitting Unit, to the User, to people and/or property. AUTEC LIUPJQ001_eng-00...
- Page 34 9.3.2 Shoulder harness Assembly LIUPJQ001_eng-00 AUTEC...
- Page 35 AUTEC LIUPJQ001_eng-00...
- Page 36 If the Transmitting Unit and the belt are used in a different way from the one described in the above mentioned figure, this constitutes improper use and may lead to damage to the Transmitting Unit, to the User, to people and/or property. LIUPJQ001_eng-00 AUTEC...
-
Page 37: Maintenance
LED emits three long blinks. paragraph 8.7). At Radio Remote Control start The SAFETY command is Bring the actuators to the rest up, the green LED is off and the activated (see Technical Data position. red LED emits four long blinks. Sheet). AUTEC LIUPJQ001_eng-00... - Page 38 The Transmitting Unit switches off 3.5 minutes after the red LED has been blinking fast. To correctly view signals displayed at the Radio Remote Control start up, press the START pushbutton and hold it pressed until the Transmitting Unit switches off. LIUPJQ001_eng-00 AUTEC...
-
Page 39: Display
(where "Direct" stands for paragraph 11.3. commands H1-H8 is activated. "Direction"). At Radio Remote Control start At least one of the actuators up, the display shows "Direct L corresponding to direction active" (where "Direct" stands for commands L1-L8 is activated. "Direction"). AUTEC LIUPJQ001_eng-00... -
Page 40: Identifying The Activated Command
11 11 Digital active 11 12 Digital active 11 13 Digital active 11 14 Digital active 11 15 Digital active 11 16 Digital active 11 17 Digital active 11 18 Digital active 11 19 Digital active 11 20 LIUPJQ001_eng-00 AUTEC... - Page 41 Direct H active 09 05 Direct H active 09 06 Direct H active 09 07 Direct H active 09 08 Direct L active 10 01 Direct L active 10 02 Direct L active 10 03 Direct L active 10 04 AUTEC LIUPJQ001_eng-00...
-
Page 42: Decommissioning And Disposal
L1 is activated. Decommissioning and disposal Instructions for correct decommissioning and disposal of Radio Remote Controls are described in chapter "Decommissioning and disposal" in "Part A" of the Instruction Manual. Therefore, please refer to that part of the Manual. LIUPJQ001_eng-00 AUTEC... - Page 43 AUTEC LIUPJQ001_eng-00...
- Page 44 Via Pomaroli, 65 - 36030 Caldogno (VI) - Italy Tel. +39 0444 901000 - Fax +39 0444 901011 info@autecsafety.com - www.autecsafety.com MADE IN ITALY...
