Inner Parts Of The "Master/Slave" Receiving Units - AUTEC Modular series User Manual

Climatic
conditions
Working
Storage
Transportation
3.2

Inner parts of the "Master/Slave" receiving units

Mother board The mother board in the receiving units is the E16B14AC.
Bus board of the The receiving unit URX-1 contains the bus board E16RI02B.
unit URX-1
See paragraph 8.4 to program the bus board E16RI02B.
Bus board of the The receiving unit URX-2 contains the bus board E16RI02D, where two radio receiving module
unit URX-2 have their seats; the one corresponds to the transmitting unit UTX-M and the other to the UTX-
S.
Position of the two radio receiving module is the one showed in the previous photo.
Frequencies set in the two radio receiving modules must undergo the following
rules:
- the radio receiving module corresponding to the transmitting unit UTX-M must
have the same working frequency as the transmitting unit UTX-M
- the radio receiving module corresponding to the transmitting unit UTX-S must
have the same working frequency as the transmitting unit UTX-S.
See paragraph 8.4 to program the bus board E16RI02D.
LIMM&SA0-00.fm
Temperature
Class 4K4H
-5°F to +160°F
4% to 100% (0,9 g/m
(-20°C to +70°C)
Class 1K5
-40°F to + 160°F
5% to 95% (1 g/m
(-40°C to +70°C)
Class 2K3
-13°F to + 160°F
(-25°C to +70°C)
F5
F4
F3
F2
F1
F1 POWER SUPPLY protection fuse
STOP circuit protection fuses
F2 and F3
F4 and F5 SAFETY circuit protection fuses
Relative Humidity
Class 4K4H
3 3
to 36 g/m )
Class 1K3
3 3
to 29 g/m )
Class 2K3
3
95% (60 g/m )
Radio receiving module
corresponding to the UTX-S
Radio receiving module
corresponding to the UTX-M
Air Pressure
Class 4K4H
86 kPa to 106 kPa
Class 1K4
86 kPa to 106 kPa
Class 2K3
70 kPa to 106 kPa
