3.7

External signal lights of the receiving unit

POWER ENABLE Each receiving unit is equipped with a status indicating light:
light
ENABLED lights The receiving unit URX-2 has two "ENABLED" lights that indicate its status in relation to the
in "Master/ transmitting units:
Slave"
Signal type
Steady light
ENABLED lights The receiving units have two "ENABLED" lights that indicate their status in relation to the trans-
in "Master/ mitting units:
Master"
Signal type
in the unit URX-1
Steady light
in the unit URX-1
in the unit URX-2
Steady light
in the unit URX-2
LIMM&SA0-00.fm
Signal type
Light switched off receiving unit not powered on
receiving unit powered on
Steady light
(POWER ON)
radio link between transmitting and
Blinking light
receiving unit is present (ENABLE ON)
ENABLED UTX-M
the receiving unit URX-2 is free from
Light off
the transmitting unit UTX-M
the receiving unit URX-2 is engaged by
the transmitting unit UTX-M
ENABLED UTX-M
the receiving unit URX-1 is free from
Light off
the transmitting unit UTX-M
the receiving unit URX-1 is engaged by
the transmitting unit UTX-M
the receiving unit URX-2 is free from
Light off
the transmitting unit UTX-M
the receiving unit URX-2 is engaged by
the transmitting unit UTX-M
Meaning
ENABLED UTX-S
the receiving unit URX-2 is free from
the transmitting unit UTX-S
the receiving unit URX-2 is engaged by
the transmitting unit UTX-S
ENABLED UTX-S
the receiving unit URX-1 is free from
the transmitting unit UTX-S
the receiving unit URX-1 is engaged by
the transmitting unit UTX-S
the receiving unit URX-2 is free from
the transmitting unit UTX-S
the receiving unit URX-2 is engaged by
the transmitting unit UTX-S
ENABLED UTX-M
ENABLED UTX-S
