NOTE:
If the selected DVR channel attribute is programmed as Simplex, the local voice repeat
DVR function is not available. If proxying and In-Car Monitor are enabled and the TG
selected by the local PSU is different from that selected on the MSU, then Inbound or
Outbound speaker audio will depend on the MSU ICM setting ('ICM Selected' or 'ICM
All') as well as the ICM trigger as described in the In Car Monitor (ICM) section of this
document.

LOCAL Mode

ACTIVITY
Control Head Display
DVRS Active Tones
DVRS Button Press
MSU Receiving from System
MSU User PTTs the MSU
Microphone
PSU Activity on DVR channel

Table 13 LOCAL Mode DVRS Basic Operation

January 2019
LOCAL MODE ACTION
VR LOC <DVR CH Name>
If programmed, a short high-pitched 'DVR
Enabled' tone is repeated every few
seconds (5-255 sec. programmable) in the
MSU Speaker regardless of the Primary /
Secondary Status of the DVR.
Short high-pitched tone.
DVR Control Mode is accessible.
DVR may be programmed to repeat audio
received by MSU to the PSU Users over the
DVR Channel when the DVR is idle.
Speaker Audio is present.
DVR keys up. MSU may or may not key up
depending on MSU programming.
PSU audio is repeated locally by DVRS.
Speaker Audio is present if In-Car Monitor
is enabled in the MSU.
