Appendix 1 – DVR Specifications
General Specifications
Dimensions: Height / Width / Depth
Channel Spacing
Number of Channels
DC Current Drain
Standby/Receive
Operating Temperature
Protection Against Liquids
Antenna Impedance
External Connectors
Computer Interface
Equipment Type Acceptance
Transmitter Specification
Frequency Band [MHz]
Power Output at TX Connector
Standalone Mode:
FCC Simultaneous DVRS
Repeated and Mobile Operation:
Max Spurious Output
Frequency Stability
FM Hum and Noise
January 2019
185mm (7.28") / 186mm (7.32") / 315mm (12.41")
Weight 10.3kg (22.7lb)
12.5 or 25 kHz programmable
192
CTCSS/DCS Programmable per Channel
Power Supply 13.8V DC +/- 20%
RPTR Off 0.01 A Max
0.8 A Max
Transmit 4.5 A Max
-30ºC to +60ºC
IP6 (water jet proof)
50 Ohms
Antenna Mini UHF
USB
FCC
LO6-DVRSVHF
Industry Canada
2098B-DVRSVHF
136-174
20 W Max. (programmable per channel from
5W, 6W, 10W or 20W Max. (programmable
Refer to RF Safety Booklet for maximum
allowed power output for specific approved
personnel at time of DVRS installation in
accordance with approved DVRS, Mobile
CCT Option
12.5 / 25 kHz
Audio Response
Audio Distortion
VHF UHF
LO6-DVRSUHF
2098B-DVRSUHF
VHF UHF
380-430
450-470
470-512
1 W Min.)
per channel from 1 W Min.)
DVRS, Mobile Radio and antenna
combinations
Maximum DVRS power output is
programmed by authorized service
Radio and antenna combinations.
Power output cannot be changed by the
operator
15 sec to 15 min or Disabled
-60dBc
+/- 1.5ppm
37 dB / 43 dB
+1, -3 dB of 6 dB / octave pre-emphasis
characteristic over 300 Hz – 3 kHz
<2%
8A083X30 Rev.11
APX Series P25 Interface
DVRS User's Guide
700 800
LO6-DVRS700 LO6-DVRS800
2098B-DVRS700 2098B-DVRS800
700 800
764-776 851-870
