APX Series P25 Interface

DVRS User's Guide
When strapping is enabled, and the DVR channel follows the MSU TG/mode selection,
the user may still be allowed (if enabled by the DVR programmed personality) to change
the DVR channel by pressing the DVRS button and then turning the mode knob.
NOTE:
Depending on the specific DVR personality programming, the DVR channel selection
may be restricted to a short list of allowed DVR channels (or no channel selection
options at all). If channel strapping is enabled then the DVR will always land on the
specified strapped DVR channel first even when more than one channels are on its
allowed channels list. For example, when TG named 'DISPATCH' is selected on the O5,
the DVR automatically lands on DVR CH 1 and the User may be allowed to toggle
between DVR Channels 1 and 4 while the selection of DVR channels 2 and 3 may be
prohibited.
