GB.GOLDINE120.130915
Instructions for Installation
GOLD RX/CX, sizes 100/120
The document was originally written in Swedish.
www.swegon.com
1
Swegon reserves the right to alter specifications.

Advertisement

Table of Contents
loading

Related Manuals for Swegon GOLD RX Series

Summary of Contents for Swegon GOLD RX Series

  • Page 1 GB.GOLDINE120.130915 Instructions for Installation GOLD RX/CX, sizes 100/120 The document was originally written in Swedish. www.swegon.com Swegon reserves the right to alter specifications.

  • Page 2: Table Of Contents

    1.16 Installation of pipework package (GOLD CX only) ............29 2. Dimensions ..........29 2.1 GOLD RX 100/120 ..........29 2.2 GOLD CX 100/120 ..........30 3. Explanation – wiring terminals, control unit ..........31 www.swegon.com Swegon reserves the right to alter specifications.

  • Page 3: Installation

    For dimensions and weights, see Section 2.2. www.swegon.com Swegon reserves the right to alter specifications.

  • Page 4: Lifting

    1.6.2 With a crane 1.6.2.1 Complete units NOTE! A line spreader must NOTE! A line spreader must be used! be used! NOTE! High centre of gravity! Other sections Rotary heat exchanger (GOLD RX only). www.swegon.com Swegon reserves the right to alter specifications.

  • Page 5: Heat Exchanger Section, Supplied Split Into Two Casing Sections And Rotor (Gold Rx Only)

    GB.GOLDINE120.130915 1.6.2.2 Heat exchanger section, supplied split into two casing sections and rotor (GOLD RX only) NOTE! A line spreader must be used! Upper casing section Lower casing section www.swegon.com Swegon reserves the right to alter specifications.
  • Page 6 Remove the wooden stud Protecting plate NOTE! Carefully raise the rotor so that it will not be damaged! Make sure that the lifting device rests against the protecting plate at the top edge. www.swegon.com Swegon reserves the right to alter specifications.

  • Page 7: To Assemble The Heat Exchanger Unit Section, If Required (Gold Rx Only)

    If the heat exchanger unit section is supplied as one unit, go on to Section 1.8. 1.7.1 Alternative 1 Remove the upper shaft bracket and the sealing plate (2x) Shaft mounting brackets Lower casing section www.swegon.com Swegon reserves the right to alter specifications.
  • Page 8 NOTE! IMPORTANT! The smooth side of the rotor hub (with- out holes) should face the pressing roller! Be careful not to damage the rotor! Pressing roller Hub side Mount the upper shaft bracket and the sealing plate (2x) www.swegon.com Swegon reserves the right to alter specifications.
  • Page 9 2 x 6 2 x 4 Fix the upper casing section to the lower casing section with the bolts supplied, screwing them into the pre-fitted rivet nuts (a total of 20 pcs.). www.swegon.com Swegon reserves the right to alter specifications.
  • Page 10 Move the electrical equipment cubicle back into position and secure it with the appropriate bolts. See also Section 1.7.3 Common for Alternatives 1 and 2 www.swegon.com Swegon reserves the right to alter specifications.

  • Page 11: Alternative 2

    (2x) ment cubicle to the main switch. Lower casing section Shaft mounting brackets Dismantle the heat exchanger motor + mounting bracket (6 bolts). Remove the sealing plate and tube. www.swegon.com Swegon reserves the right to alter specifications.
  • Page 12 NOTE! IMPORTANT! The smooth side of the rotor hub (with- out holes) should face the pressing roller! Be careful not to damage the rotor! Pressing roller Hub side Mount the upper shaft bracket and the sealing plate (2x) www.swegon.com Swegon reserves the right to alter specifications.
  • Page 13 Secure the motor + mounting bracket and the heat exchanger drive motor. Move the electrical equip- with bolts (6 bolts). ment cubicle back into position and secure it with the appropri- ate bolts. www.swegon.com Swegon reserves the right to alter specifications.
  • Page 14 Fix the upper casing section to the lower casing section with the bolts supplied, screwing them into the pre-fitted rivet nuts (a total of 16 pcs.). See also Section 1.7.3 Common for Alternatives 1 and 2 www.swegon.com Swegon reserves the right to alter specifications.

  • Page 15: Common For Alternatives 1 And 2

    Do not dismantle the shaft bracket. Adjust the inclination of the rotor by means of the adjusting bolts. Tighten the adjusting bolts equally. When you have adjusted the inclination, tighten the locking bolts. www.swegon.com Swegon reserves the right to alter specifications.

  • Page 16: Sealing Plates/Purging Sector

    Slip the vinyl-coated fabric seal of the rotor (blue) over the rim all the way around on both sides of the rotor. Tension the pressing roller against the rotor hub until you no longer can roll the pressing roller with your hand. www.swegon.com Swegon reserves the right to alter specifications.

  • Page 17: Sealing

    (front and rear). Apply appropriate sealing compound/ putty around the sealing plate of the rotor shaft (2 plates). www.swegon.com Swegon reserves the right to alter specifications.

  • Page 18: Decorative Fittings

    GB. GOLDINE120.130915 1.7.3.6 Decorative fittings Mount the decorative fittings with self-tap- ping screws in the pre-punched holes. Mount the decorative fittings with the pre-fitted M5 bolts in the pre-fitted rivet nuts. www.swegon.com Swegon reserves the right to alter specifications.

  • Page 19: Transport Locking Devices, Fans

    Fan arrangement 4, supply air – upper level supply air - lower level Right-hand version Left-hand version Fan arrangement 1 Fan arrangement 2 Outdoor air Supply air Extract air Exhaust air Left-hand version www.swegon.com Swegon reserves the right to alter specifications.

  • Page 20: The Docking Of Unit Sections

    Section 1.9). Fix the fan/filter sections at thefront side of the air handling unit to the heat exchanger section with the bolts supplied, screwing them into the pre- fitted rivet nuts (a total of 2x4 pcs.). www.swegon.com Swegon reserves the right to alter specifications.

  • Page 21: Fixation, Rear Of The Unit

    You can then tighten the screws from the opening of the duct connection. NOTE! You do not need to remove the fan assemblies completely! www.swegon.com Swegon reserves the right to alter specifications.

  • Page 22: Decorative Fittings

    Press the decorative fittings firmly into the base beam to engage them. GOLD CX: Fit the decorative plate with cable grommets on the heat exchanger section. www.swegon.com Swegon reserves the right to alter specifications.

  • Page 23: Electrical Quick-Fit Connectors

    The illustration shows the GOLD RX, fan arrangement 2. The principle is however the same for the other air handling units. GOLD 100 GOLD 120 GOLD 100 GOLD 120 www.swegon.com Swegon reserves the right to alter specifications.

  • Page 24: To Connect Air Tubes To Filter Pressure Sensors

    (below the filter) and are rolled up inside each fan/filter section. The illustration shows the GOLD RX, fan arrangement 2. The principle is however the same for other air handling units. www.swegon.com Swegon reserves the right to alter specifications.

  • Page 25: Duct Connection

    4. Connect the sensor's quick-fit connector to the appro- priate socket on the control circuit board of the air handling unit. See Section 1.15. A >= 1500 mm = 10000 mm = Ø 11 mm www.swegon.com Swegon reserves the right to alter specifications.

  • Page 26: Electrical Connections, Protective Motor Switch And Communication Cables (Gold Cx Only)

    Sensor 1, 2, 3 or 4 COM6-11 and should be and should be connected connected in an optional to the corresponding bus bus contact marked COM6- contact. www.swegon.com Swegon reserves the right to alter specifications.

  • Page 27: To Connect The Electric Power Supply

    3-phase, 5-wire cable, 400V -10/+15%, 50/60 Hz, 80 AT. GOLD RX/CX 120, capacity variant 2: 3-phase, 5-wire cable, 400V -10/+15%, 50/60 Hz, 125 AT. L1 L2 L3 N Wiring terminals, safety isolating switch L1 L2 L3 N Safety isolating switch www.swegon.com Swegon reserves the right to alter specifications.

  • Page 28: To Connect External Cables

    Decorative fitting Decorative fitting Cable Service hatch Cable Blanking plate, electri- Cover panel cal equipment cubicle Control circuit board inside the Control circuit board inside the electrical equipment cubicle electrical equipment cubicle www.swegon.com Swegon reserves the right to alter specifications.

  • Page 29: Installation Of Pipework Package

    Heat exchanger section, supplied in two casing sec- tions + rotor Lower casing section = 494 kg Upper casing section = 270 kg Rotor = 410 kg) Transport cradle = 190 kg www.swegon.com Swegon reserves the right to alter specifications.

  • Page 30: Gold Cx 100/120

    1200 2400 3440 3322 2500 1720 4754 Individual weights Filter section GOLD 100/120: 529 kg/pc. Fan section GOLD 100: 834 kg/pc. GOLD 120: 968 kg/pc. Heat exchanger section GOLD 100/120: 880 kg/pc. www.swegon.com Swegon reserves the right to alter specifications.

  • Page 31: Control Unit

    The max permissible common load on terminals 31-32, outputs for Heat/Cool and damper output (terminals 28-30) is 50 VA. GOLD 100/120: If more than 16 VA is required, use wiring terminals 201 (G) and 202 (G0). Terminals 201-202 can be loaded with a total of max. 48 VA. www.swegon.com Swegon reserves the right to alter specifications.
  • Page 32 GB. GOLDINE120.130915 www.swegon.com Swegon reserves the right to alter specifications.
