REMS Multi-Push SL Instruction Manual page 21

eng
Fine fi lter cartridge 90 µm
Caps 1" with chain (REMS Multi-Push)
Plugs 1" with chain (suction/pressure hoses)
Plugs ½" with chain (REMS Multi-Push)
Caps ½" with chain (high-pressure hose)
Pressure gauge 6 MPa/60 bar /870 psi
Fine scaled pressure gauge 1.6 MPa/16 bar/232 psi,
Fine scaled pressure gauge 250 hPa/250 mbar/3.6 psi,
1.3 Applications
Device storage temperature
Water temperature
Ambient temperature
pH value
Smallest test volume
Compressor Compressor
Operating pressure
Oil separation rate
Extraction rate
Compressed air vessel volume (Fig. 1 (35))
Condensation and particle fi lter
Flushing of pipe systems Flushing of pipe systems
Flushing water connections
Water pressure pipe network
Water pressure when fl ushing with compressed air ≤ 0.7 MPa/7 bar/101 psi
Water fl ow rate
Pipe diameter installation
Pressure testing Pressure testing of drinking water installations f drinking water installations
Pressure test with compressed air
Reading accuracy < 200 mbar
Reading accuracy ≥ 200 mbar
Pressure test with water
Reading accuracy
Pressure testing of gas installations Pressure testing of gas installations
Pressure test with compressed air
Reading accuracy < 200 mbar
Reading accuracy ≥ 200 mbar
1.4 Electrical/electronic data
Type of protection terminal box
Type of protection device, motor
Protection class
Operating mode (continuous operation)
Screen (LCD)
Resolution
Data transfer with USB stick
Printer, battery
Charger printer
1.5 Dimensions L × W × H
Paper roll printer B × Ø
1.6 Weight
REMS Multi-Push SL
REMS Multi-Push SLW
1.7 Noise information
Work place-related
Emission value
2 Start-up
CAUTION CAUTION
Transport weights above 35 kg must be carried by at least 2 persons.
NOTICE
REMS Multi-Push is not intended/suitable for permanent connection to the
installation. Disconnect all hoses from the installation after completing the work.
REMS Multi-Push may not be operated unattended.
2.1 Electrical connection
WARNING
Caution: Mains voltage present! Before connecting the electronic fl ushing and
pressure testing unit, check whether the voltage given on the rating plate corre-
sponds to the mains voltage. Only use sockets/extension leads with a functioning
PE contact. The function of the PRCD fault current circuit breaker (Fig. 1 (1))
must be checked every time before start-up and before beginning work:
1. Plug the mains plug into the socket.
2. Press the RESET button (2), the PRCD control lamp (Fig. 1 (39)) lights red
(operating state).
3. Pull out the mains plug, the PRCD control lamp (39) must go out.
4. Plug the mains plug back into the socket.
5°C – 35°C
5°C – 40°C
approx. 10 l
≤ 0.8 MPa/8 bar/116 psi
≤ 230 Nl/min
≤ 1 MPa/10 bar/145 psi
≤ DN 50, 2"
≤ 0.4 MPa/4 bar/58 psi
1 hPa/1 mbar/0.015 psi
100 hPa/0,1 bar/1.5 psi
≤ 1.8 MPa/18 ba r/261 psi
0.02 MPa/0.2 bar/3 psi
≤ 0.3 MPa/3 bar/44 psi
10 Pa/0,1 mbar/0.002 psi
100 hPa/0,1 bar/1.5 psi
230 V~; 50 Hz; 1,500 W
110 V~; 50 Hz; 1,500 W
128 × 64 bits
Ni-Mh 6 V – ---; 800 mAh
Input 100 – 240 V~; 50 – 60 Hz; 0.15 A
5 V – ---; 680 mA
Output
570 × 370 × 530 mm (22.4" × 14.6" × 20.9")
57 × ≤ 33 mm
36.7 kg (81 lb)
39.0 kg (86 lb)
L = 73 dB(A); L = 73 dB(A); L = 73 dB(A); L = 92 dB(A); K = ± 1 dB = 73 dB(A); L
PA PA PA WA WA
043054 5. Press the RESET button (2), the PRCD control lamp (39) lights red (oper-
115619 ating state).
115620 6. Press the TEST button (3), the PRCD control lamp (39) must go out.
115624 7. Press the RESET button (2) again, the PRCD control lamp (39) lights red.
The control lamp (Fig. 2 (5)) lights green. REMS Multi-Push is ready for
115623
operation after about 10 s.
115140
115045
WARNING
047069
If the described functions of the PRCD fault current circuit breaker (Fig. 1 (1))
are not fulfi lled, the device may not be used. There is a danger of electric shock.
≥ 5°C The PRCD fault current circuit breaker tests the connected device, not the
installation before the socket nor interconnected extension leads or cable reels.
On building sites, in a wet environment, indoors and outdoors or under similar
6,5 – 9,5
installation conditions, only operate the electronic fl ushing and pressure testing
unit on the mains with a fault current protection switch (FI switch) which interrupts
the power supply as soon as the leakage current to earth exceeds 30 mA for
200 ms. A cable cross-section that corresponds to the power of the electronic
fl ushing and pressure testing unit must be selected when using an extension
oil-free
lead.
4.9 l
Flushing
5 µm
Ingredients
Testing
DN 25, 1"
Compressed Air Pump
Memory Manager
≤ 5 m³/h
Press the On/Off button on the input and control unit's operating panel (Fig. 2
(4)) for approx. 2 s, then release it. REMS Multi-Push is switched on and the
compressor switches on. The screen (6) is illuminated and the Logo REMS
Multi-Push logo appears followed by the Start menu:
2.2 Menu structure and on-screen displays
Five main programs of the REMS Multi-Push are displayed in the Start menu:
Flushing, Ingredients, Testing, Compressed Air Pump, Memory Manager. The
screen display contains a maximum 5 lines with 20 characters each. Lines with
defaults or test values are displayed language-independently with physical
formula symbols, a uniform verbal abbreviation and the value of the test crite-
rion in the sub-routines. These have the following meanings:
p refer bar xxx
p refer mbar xxx
p actual bar xxx
IP 44
p actual mbar xxx
IP 20
p diff bar xxx
I p diff mbar xxx
t stabi min xxx
S 1
t test min xxx
3.0"
Δ > 10K
PfS
USB port
P+M
p H O bar
2
v H O m/s
2
t H O min
2
n H O n-times
2
VA H O l
2
VS H O l/min
2
V H O l
2
File no.
max. DN
Enter
Esc
Ver. Software
2.3 Settings menu
NOTICE
The defaults for the different test criteria in the Settings menu of the REMS
Multi-Push are taken from the EN 806-4:2010 or the information leafl et "Leak
tests of drinking water installations with compressed air, inert gas or water"
(January 2011) of the German Central Association for Sanitary, Heating and
Air Conditioning (ZVSHK) as well as the Technical Rule "Technical Rule for
Gas Installations Worksheet G 600 April 2008 DVGW-TRGI 2008" of the DVGW
German Gas and Water Association. All defaults for the test programs can be
edited by the user in the Settings menu and in the Flushing, Test with compressed
air, Test with water and Compressed Air Pump programs
Settings menu are saved, i.e. they reappear the next time the REMS Multi-Push
is switched on. If the defaults are only changed in one of the programs
original defaults appear again the next time the REMS Multi-Push is switched
on. Reset resets all defaults to factory settings and the language to German
and the date, time, units formats to DD.MM.YYYY, 24 h, m/bar.
Attention: The user is solely responsible for transferred or newly entered
test criteria (test sequences, pressures and times) or defaults in the
individual programs and the conclusions from the tests.
The respective national safety provisions, rules and regulations valid for
the application site must be considered and observed.
Before using the REMS Multi-Push, check whether the respective latest version
software is installed on the input and control unit. Select the Settings menu and
reference test pressure bar
reference test pressure mbar
actual test pressure bar
actual test pressure mbar
differential test pressure bar
differential test pressure mbar
stabilisation/wait time min
test time min
difference >10°C (10 Kelvin) water/environment
press fi tting system (ZVSHK)
load test plastic + metal
water pressure
minimum fl ow speed
fl ushing/disinfecting/cleaning/preservation time
water change
volume of the fl ushing section
volume fl ow
used water volume
memory location no. for measuring log
largest rated diameter
next screen display
previous screen display or cancel
version software
programs. Changes in the
eng
programs, the
21
