WARNING
To prevent fire or shock hazard, do not expose
the unit to rain or moisture.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
This symbol is intended to alert the
user to the presence of uninsulated
"dangerous voltage" within the
product's enclosure that may be of
sufficient magnitude to constitute a
risk of electric shock to persons.
This symbol is intended to alert the
user to the presence of important
operating
(servicing) instructions in the
literature accompanying the unit.

Introduction

and
maintenance
INFORMATION
This equipment generates and uses radio frequency
energy and if not installed and used properly; that is,
in strict accordance with t he manu facturer's
instructions, may cause interference to radio and
television reception. It has been type tested and
found to comply with the limitations for a Class B
comput ing device in accordance with th e
specifications in Subpart J of Part 15 of the FCC
Rules, which are designed to provide reasonable
protection against such interference in a residential
installation. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause interference to radio or
television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment to an outlet of a circuit
different from t hat to which t he receiver is
connected.
- Consult the dealer or on experienced radio/TV
technicion for help.
TO PREVENT ELECTRIC SHOCK, DO NOT USE
THIS POLARIZE D AC PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER
OUTLET, UNLESS THE BLADES CAN BE FULLY
INSERTED TO PREVENT BLADE EXPOSURE.
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDS-481L and is the answer not in the manual?

Questions and answers

Related Manuals for Commax CDS-481L

Summary of Contents for Commax CDS-481L

  • Page 1: Introduction

    Introduction WARNING INFORMATION To prevent fire or shock hazard, do not expose This equipment generates and uses radio frequency the unit to rain or moisture. energy and if not installed and used properly; that is, in strict accordance with t he manu facturer’s instructions, may cause interference to radio and CAUTION television reception.

  • Page 2: Important Safety Instructions

    Important Safety Instructions 1. Read Instructions - All the safety and operating 9. A product and cart instructions should be read before the product is combination should be operated. moved with care. Quick stops, excessive force, and 2. Retain Instructions - The safety and operating uneven surfaces may instructions should be retained for fu ture cause the product and...
  • Page 3 Important Safety Instructions 13. Power-Card Protection - Power-supply cords 17. Power Lines - An outside antenna system should should be routed so that they are not likely to be not be located in the vicinity of overhead power walked on or pinched by items placed upon or lines or other electric light or power circuits, or against them paying particular attention to where it can fall into such power lines or...
  • Page 4 Important Safety Instructions 23. Safety Check - Upon completion of any service D. If the product does not operate normally by following the operating instructions. Adjust or repairs to this product, ask the service only those controls that are covered by the technician to perform safety checks to determine operating instructions, as an improper that the product is in proper operating...

  • Page 5: Table Of Contents

    Table of Contents Introduction ..........................1 Important Safety Instructions ..................... 2 Table of Contents ........................5 1. Greeting.......................... 6 2. Before Getting Started ..................... 6 3. Overview 3-1. Overview ....................... 7 3-2. Essentials......................... 8 4. To Connect with Households 4-1. Being Paged by the Household................10 4-1-1.

  • Page 6: Greeting

    1. Greeting ● Thank you for purchasing a Commax product. ● This state-of-the-art Guardhouse Interphone switchboard contains the parking management system, individual household checking feature, and various other essential services in security. Please read this user manual carefully and familiarize yourself with its contents before use.

  • Page 7: Overview

    3. Overview 3-1. Overview Number Description Description Number Time Adjustment Button Speed Dial Buttons Household Selection Button P.A. Button Call Connection Button Enter Button Speakerphone Away Button Call Button Remote Control Button Parking Management System Extension Button Emergency Lamp Redial Button Away Lamp Volume Adjustment Call Lamp...

  • Page 8: Essentials

    3-2. Essentials *Household Selection Button/Lamp: Used to select one of the Households indicated on the Household Indicator Section. *Time Adjustment Button/Lamp: Used to adjust time. *Enter Button/Lamp: Used to execute the Guardhouse Interphone’s programs.\ *Confirmation Button/Lamp: Used to confirm changes made to data within the Guardhouse Interphone’s programs.
  • Page 9 * Key Pad: Used to enter in numbers. * Building Button: Used to distinguish buildings when entering Household numbers. * Call Button (#): Used to page after entering a Household number.\ * P.A. Button/Lamp: Used for announcements among Guardhouses * Call Connect Button/Lamp: Used to connect a Hou sehold to another Household or another Guardhouse.

  • Page 10: To Connect With Households

    4. To Connect with Households 4-1. Being Paged by the Household ① A paging signal will sound from the Guardhouse interphone when a Household has paged the Guardhouse. C a l l < 0 1 0 1 - 0 1 0 1 Pickup the Receiver to answer.

  • Page 11: Paging The Household From The Guardhouse (Paging Another Guardhouse)

    4-2. Paging the Household from the Guardhouse (Paging another Guardhouse) ① Pickup the receiver and enter the Building Number of the Household to connect to using the Key Pad. (To page another Guardhouse, enter in 9999) Ex) Unit 101 ② Press the Building button (✽). (The number indicated on the LCD and the Guardhouse Indicator Section moves to the Building location) Building button ③...

  • Page 12: To Connect A Household With Another Household

    5. To Connect a Household with another Household ※ (Warning) Guardhouse calls cannot be forwarded. ① When a request to connect to another household has been made while connected to the Household, ② Press the Call Connection button. (The lamp will light up) ③...

  • Page 13: Selecting And Answering Missed

    6. Selecting and Answering Missed Pages ① When a Household page has been made while the Guardhouse Interphone’s line was busy, the Household Number where the page originated from and the Household Selection Button/Lamp light up on the Household Indicator Section. “...

  • Page 14: Connecting To The Main Entrance

    7. Connecting to the Main Entrance 7-1. To Connect to the Guardhouse from the Main Entrance ① A paging signal will sound when the Guardhouse has been paged from the Main Entrance. (Main Entrance Number indicated on the LCD and the Guardhouse Indicator Section) C a l l <...

  • Page 15: To Connect To The Main Entrance From The Guardhouse

    7-2. To Connect to the Main Entrance From the Guardhouse ① Pickup the receiver and press the number of the entrance to connect to. Ex) To connect to the first Main Entrance of ② Press the Page button. Building 101. A Paging Signal will Sound Page button...

  • Page 16: Paging And Connecting To A Household Using Registered Vehicle Numbers (Parking Management System)

    8. Paging and Connecting to a Household using Registered Vehicle Numbers (Parking Management System) This feature is only available when Vehicle Numbers have been registered to each Household. (Refer to the registration method in 16-2) ① Pickup the receiver and enter the number of the vehicle registered in the Parking Management System.(‘car>...

  • Page 17: Announcement

    9. Announcement ① Pickup the receiver and enter the group number to announce to using the Key Pad. ② Press the P.A. button. Announcement Indication Signal will Sound ③ After the announcement indication sounds, make the announcement. Start the Announcement <Note>...

  • Page 18: Call Block

    10. Call Block * Used when the Guardhouse is left unattended. (This feature is only available when data has been entered into Pr03 from “Guardhouse Interphone Program Confirmation and Modification’) * This feature is disabled when the Guardhouse interphone has been turned off, then on. ①...

  • Page 19: Away Mode Setting And Security Mode Extension From The Guardhouse

    11. Away Mode Setting and Security Mode Extension from the Guardhouse * When the Away Status has been registered at the Guardhouse for a Household, that Household will go into Security Mode right away. (If a door installed with security sensors within the Household is opened, Security Mode will not be activated) * Security Guard Activation Delay is not cancellation of the Away Mode but is a feature that delays the activation time of Household Security Guard.
  • Page 20 ⑤ Press the Speakerphone button to end. 11-2. Verifying Away Status of the Household from the Guardhouse ① Pickup the receiver or press the Speakerphone button. ② Enter the Building and Household Number and press the Call button. Call button Building button ③...
  • Page 21 11-3. Security Guard Delay from the Guardhouse ① Press the Remote Control button. ② Enter the Building Number and the Household Number and press the Away button. Building button ③ When the Security Guard has been delayed, the following will appear on the LCD: S e n s o r C h k W a i t ④...

  • Page 22: Emergencies Within Households

    12. Emergencies within Households 12-1. Sensor Caused Emergencies (Maximum 4 emergency indications can be made simultaneously. (Maximum 16 emergency notifications)) ① Emergency notifications are transmitted to all connected Guardhouse Interphones. (Designated by the Selection Switch No.2 on page 6) ② Siren will sound and Building and Household numbers will blink on the Household Indicator Section.
  • Page 23 ② Household with the emergency is indicated on the Guardhouse Indicator Section. ③ When the blinking stops, the page is made. * Alarm corresponding to the emergency is sounded. Electronic Gun: Emergency Fire Truck: Fire Ambulance: Gas Leak Police Siren: Burglar Intrusion If the Household cannot sound alarms, each of the following situations is indicated: In state of emergency - Emergency Fire detection - Fire...

  • Page 24: Delivery

    13. Delivery When the Household pages the Guardhouse, the page is routed to the Guardhouse that has made the Delivery Page. ① Press the Speakerphone button. ② Enter the Building Number, press the Building button, and enter the Household Number. Building button ③...

  • Page 25: Confirming Household Conditions

    14. Confirming Household Conditions 14-1. To Confirm Household Conditions (1 Household) ① Press the Remote Control button. (‘Rmot> - “ will display on the LCD) R m o t > ② Enter the Building Number, press the Building button, enter the Household Number, and press the Extension button.
  • Page 26 A. Household’s Current Status Indicates the Household’s status, indicated by the following: Normal: Normal Status Emergency: Emergency Situation Fire: Activation of Fire Sensors within the Household Gas: Activation of Gas Detectors within the Household Burglar: Detection of Intrusion Out Door House: Residences Away Busy: The Household is currently on a call.
  • Page 27 C. Household Sensor Status Indicates the status of each sensor in the Household. Emergency: Fire: Gas: Security 1: Security 2: Security 3: Security 4: Emergency: Emergency switch within the Household activated (1) Fire: Fire sensor within the Household activated (1) Gas: Gas detectors within the Household activated (1) Security 1: Security 1 activated (1) Security 2: Security 2 activated (1)
  • Page 28 14-2. To Confirm Household Conditions (Automated, to confirm 1 building) * This feature checks all interphones installed within 1 building. * If more than one interphone is connected to a Household, only its Master is checked. ① Press the Remote Control button. R m o t >...
  • Page 29 ⑤ Enter the Household Number on the highest floor. (Do not enter the Building Number) E n d Z o n e S e l e c t ⑥ Press the Call button. Households are automatically checked. Call button Error’ will be indicated on the Guardhouse Indicator Section if an error is detected, and its details are indicated on the Household Indicator Section.

  • Page 30: Adjusting Time

    15. Adjusting Time * Do not pickup the receiver when adjusting time. ① Press the Time Adjustment button. ② Enter in the following order: YY(Year)-MM(Month)-DD(Day)-HH(Hour)-MM(Minute)-W(Day of the Week) Days of the Week - 0(Sun), 1(Mon), 2(Tue), 3(Wed), 4(Thu), 5(Fri), 6(Sat) (Enter hours based on the 24-hour clock) YY-MM-DD-HH-MM-W YY-MM-DD-HH-MM-W...

  • Page 31: Advanced Feature (Please Use Only After Understanding Its Handling To The Full)

    16. Advanced Feature (Please use only after understanding its handling to the full) 16-1. Registering Household Numbers This feature is only available when the Household has paged the Guardhouse and is still connected to the Guardhouse. (Does not function when the Household is paged by the Guardhouse) ①...
  • Page 32 ⑤ Enter the Multi Sub Number. * What is Multi Sub Number? Refers to individual numbers for each videophone in the Household when there is more than one. * The Master’s Serial Number is 0. * Sub Serial Numbers are from 1 to 9. * Maximum 10 videophones can be installed in a household, and their serial numbers must not overlap.

  • Page 33: Registering Household Vehicles (Parking Management System)

    16-2. Registering Household Vehicles (Parking Management System) * Registers two vehicles per Household, and registered vehicle numbers can be used page or reference the Household. 16-2-1. Registering with Known Vehicle Number ① Press the Speakerphone button, then the Remote Control button. (Just the Remote Control button may be pressed) ②...
  • Page 34 ③ Press either Household Selection button 1 or 2 for data modification. (Blinking light on the right half of the Household Indicator Section displays whether data can be modified or not) ④ Enter the vehicle’s region and assigned numbers. (‘*’ button distinguishes the two) Ex) Gyeonggi 32 Ga 2580 Assigned Number Region Number (1 or 2 digits)

  • Page 35: Registration By The Household Through The Guardhouse

    ⑧ Press the Speakerphone button to end. 16-2-2. Registration by the Household through the Guardhouse (Only possible when the Household pages the Guardhouse) ① Pickup the receiver and press the Remote Control button while staying connected to the Household. ② Registering Household Vehicles (Parking Management System) Mister, our vehicle number is…...

  • Page 36: Checking Household Numbers Using Vehicle Numbers

    ④ Use the (←) button to undo wrong entries. ⑤ Select from Entry 1 and Entry 2 for the entered vehicle number to store. ⑥ Put down the receiver to end. 16-3. Checking Household Numbers using Vehicle Numbers ① Press the Speakerphone button. ②...

  • Page 37: To Open Or Close The Main Entrance

    ③ Enter the vehicle’s region number, then press the Building button. Enter the vehicle’s assigned number, then press the Call button. Call button Building button Region Number (1 or 2 digits) Assigned Number(4 digits) ④ Vehicle number is displayed on the LCD, and the Household Number is displayed on the Guardhouse Indicator Section.
  • Page 38 ④ Press the Door Release button to open the entrance. ⑤ Put down the receiver to end. - 38 -...

  • Page 39: To Open The Entrance For Indefinitely

    16-4-2. To Open the Entrance for Indefinitely (Used to keep the entrance open for moving-in and etc.) ① Press the Speakerphone button. ② Enter the Building Number of the entrance, the press the Building button. Building button ③ Enter the Entrance Interphone’s Serial Number, then press the Open button. (Entrance opens) ④...

  • Page 40: To Close Main Entrances

    16-4-3. To Close Main Entrances ① Press the Door Release button. (” Lobby process” indicated on the LCD) Lobby process ② Press the Confirmation button. (“Open Lobby: XX” indicated on the LCD) XX is the number of opened entrances. (The number of opened entrance interphones is indicated on the Household Indicator Section) Open Lobby : 1 ex) One opened entrance.
  • Page 41 ③ With over 5 opened entrances, use (← , →) buttons to scroll through. ④ Use (← , →) buttons to find the entrance to close and select the entrance interphone using the Household Selection button. (Selected Entrance Interphone Number moves to the Guardhouse Indicator Section) Use (←...
  • Page 42 Guardhouse Indicator Section The first open entrance interphone The second open entrance interphone The third open entrance interphone The fourth open entrance interphone Guard : Guardhouse Indicator Section Household 1 101 - 9901: The first open entrance interphone Household 2 101 - 9902: The second open entrance interphone Household 3 101 - 9903: The third open entrance interphone Household 4 101 - 9904: The fourth open entrance interphone * To close the second open entrance (101-9902), press Open and the Confirmation button, press the...

  • Page 43: Guardhouse Interphone Program Confirmation And Modification

    17. Guardhouse Interphone Program Confirmation and Modification ① Press the Confirmation button. ( “ Password - “ indicated on the LCD) Password ② Enter in 9999, then press the Enter button. (“ Program - “ indicated on the LCD) Program ③...
  • Page 44 The following steps must be performed to store any modification to the program: (Failure to store may result in the modification not being activated) ⑥ (←, →) buttons to select Program Number 31. Pr31 [0000] ⑦ Use the Key Pad to enter in 8888, then press the Enter button ⑧...
  • Page 45 ex) Example of Guardhouse Interphone Program Confirmation and Modification ♣ Enter when the Sub building the Guardhouse Interphone is in charge of are Buildings 101 and 102 ② Enter in 9999, then press ① Press the the Enter button. Confirmation button. ③...
  • Page 46 ⑦ Use (← , →) buttons to select "Pr 31". Pr31 [0000] ⑧ Enter in "8888"(Data storage) “Prog[XXXX]Wait " will display on the LCD. Wait Prog [0000] Wait ⑨ Do not power down until the entry lamp has turned off. From now, Buildings 101 and 102 must not be overlapped as the SUB buildings of any other Guardhouse interphones.

  • Page 47: [Table 1] Guardhouse Interphone Program Number And Description

    [Table 1] Guardhouse Interphone Program Number and Description Program Description Selection Number Device Number: The Guardhouse Interphone’s Serial Enter from 0001 to Pr 00 Number 9000 Building to Building Connection 0000: 8 Circuits -0000: The line is composed of 8 circuits, and the wiring is 18-line common. Pr 01 0001: 16 Circuits -0001: The line is composed of 16 circuits, where 16- wirecommon is added.
  • Page 48 Program Description Selection Number Pr 24 Speed Dial 2 Building No. + Household No. Pr 25 Speed Dial 3 Building No. + Household No. Pr 26 Speed Dial 4 Building No. + Household No. Pr 27 Speed Dial 5 Building No. + Household No. Pr 28 Speed Dial 6 Building No.

  • Page 49: Wiring Method

    18. Wiring Method 1) Guardhouse Interphone (CDS-481L) 1-2 : Call 1 (TIV 0.65mm×2C Non Polar) 3-4 : Call 2 (TIV 0.65mm×2C Non Polar) 5-6 : Call 3 (TIV 0.65mm×2C Non Polar) 7-8 : Call 4 (TIV 0.65mm×2C Non Polar) 9-10 : Call 5 (TIV 0.65mm×2C Non Polar)
  • Page 50 2) Main Entrance Interphone (DRC-481L) *Security ① DC 12V used. Designed to be used by connecting to the lead switch. When not in use, please connect two ② wires. When the Main Entrance is opened by force, the Guardhouse and the computer are notified. ③...
  • Page 51 3) Household Videophone (CH-481SL) 4) Household Videophone (APV-481FT) - 51 -...
  • Page 52 5) Household Videophone (CAV-60FSD) 6) Household Videophone (CAV-60FD) - 52 -...
  • Page 53 7) Household Videophone (CAV-561D) - 53 -...
  • Page 54 8) Household Videophone (CAV-482S) - 54 -...
  • Page 55 9) TV-Phone Interface Adaptor(ADT-481) 10) Security Interface Adaptor(ADT-482) - 55 -...
  • Page 56 11) System Map - 56 -...
  • Page 57 12) Wiring Method for Communications with the Guardhouse - 57 -...
  • Page 58 VD/IN • VD/OUT • 3.If the Guardhouse Interphone (CDS-481L) has been installed, Number 7 (Data) and 8 (GND) connected to it must be connected to the Household Interphone. 4.Use coaxial cables (3C2V or 5C2V) for Video Out. - 58 -...
  • Page 59 14) Wiring ADT-481 and CKV-60T 15) Wiring ADT-482 and CAV-482S - 59 -...
  • Page 60 16) Installing Numerous Videophones in a Household ※ Note 1. A: Guardhouse Line (8-wire Common) B: Main Entrance Line (4-wire Common) C: Sub Extension (6-wire Common) 2.When registering the Multi Sub number, ADT-481 will not be recognized as the Master and should be installed last as shown above.
  • Page 61 17) CCTV and Sensor Wiring ※ NOTE 1.Monitor 1: To view only when being used by the Main Entrance Interphone (DRC-481L). 2.Monitor 2: Continuous surveillance of the Main Entrance. - 61 -...
