Page 1: User Manual
User Manual Color video door phone CDV-35A... -
Page 2: Table Of Contents
Table of Contents 1. Warnings and Cautions................1 Part Names and Functions ..............2 Contents ....................2 Wiring and Connection Instructions............3 Installation ....................Operation ......................4 Specifications...................6 1. Warnings and caution Please follow the things described below in order to prevent any danger or property damage. -
Page 3: Part Names And Functions
Parts Names 3. Contents Handset Monitor Manual Wall Bracket Body of CDV-35A External Menu Button Door Release Button Connection Interphone Button Terminal Monitor Button T4 X 18(4EA) M3 x 6(1EA) Power Switch... -
Page 4: Wiring And Connection Instructions
4. Wiring and Connection Instructions ▷ Polarity of interphone connector ▷ Polarity of the camera connector 1. Red: Talk (Audio) 1. Red: Talk (Audio) 3. Yellow: Power (+12V) 3. Yellow: Power (+14V) 2. Blue: GND 2. Blue: GND 4. White: Video 4. -
Page 5: Operation
6. Operation � Caution : Do not hold the handset at your ear when you press hook switch to switch call. Call from the visitor ① When the visitor calls from the entrance(door camera), the calling sound rings and the image of the visitor is shown on LCD screen. ②... - Page 6 Monitoring : Function to see the image of door camera. Operation on the Stand-by status Monitoring works as following sequence by pressing the monitor button. Camera1 (Camera2) OFF Camera1 .... Operation while talking Monitoring works as following sequence by pressing the monitor button. Camera1 ( Camera2 ) Camera1...
-
Page 7: Specifications
CONTRAST : Contrast adjustment ① Press the menu button twice when the image is on. (LED lamp will be changed from blue to red.) Red LED blinks slowly. [●●◦◦●●◦◦●●◦◦●●◦◦] ② You are in CONTRAST adjustment mode. ③ Press the UP(Door release) / DOWN(Interphone) button in front of the product in order to adjust the CONTRAST. - Page 8 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. Tel. : +82-31-7393-540~550 Fax. : +82-31-745-2133 Web site : www.commax.com PM0770N00010 Printed In Korea / 2015.12.104...
