User Manual

• Thank you for purchasing COMMAX products.

• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow

instructions to use a product exactly.

• The company is not responsible for any safety accidents caused by abnormal operation of the product.

CDS-70M

Table of Contents

Need help?

Do you have a question about the CDS-70M and is the answer not in the manual?

Questions and answers

Summary of Contents for Commax CDS-70M

Page 1: User Manual
User Manual CDS-70M • Thank you for purchasing COMMAX products. • Thank you for purchasing COMMAX products. • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly.
Page 2: Table Of Contents
8. Checking CCTV ………………………………………………………………………………………………… 9. Settings …………………………………………………………………………………………………………… 10. Wiring …………………………………………………………………………………………………………… 11. Caution in use ………………………………………………………………………………………………… 12. Miscellaneous …………………………………………………………………………………………………… 1. Greetings Thank you very much for purchasing of COMMAX products. ● Please red carefully this user manual and follow its rules. ●...
Page 3: Warning And Caution
2. Warning and caution Please follow the things described below in order to prevent any danger or property damage. Prohibition. Warning It may cause a serious damage or No disassembly injury if violated. No touch Must follow strictly. Caution Shows plugging out the power cord It may cause a minor damage or without an exception injury if violated.
Page 4 Warning Please don’ t disassemble, If an abnormal sound, burning Please don’t insert any Please use only the designated repair or rebuild this product smell or smoke is coming out metallic or burnable materials batteries for the products of arbitrarily (please contact the of the product, please plug out into the ventilation hole.
Page 5: Part Names
3. Part names Name Name Handset LAN PORT LCD (7" TFT LCD) CONSOL CCTV DIAL KEY CMOS CAMERA DC JACK (DC 14V, 2.1A) FUNCTION KEY TELEPHONE (LOCAL LOOP) POWER SWITCH...
Page 6: Composition Of The Picture
4. Composition of the picture ① ① MENU Under 4 kinds of menu such as call, security, control, handiness. various functions can be used. Call: using general telephone or calling household residents. Emergency log: checking current emergency situation Visitors: checking saved image while visitors’ call CCTV: checking CCTV images ②...
Page 7: Using Telephone Function
5. Using telephone functions. ① Telephone ② Recent call record ③ Address list ④ Favorites ⑤ inputted telephone no. ⑥ General call ⑦ Calling among households ⑧ Deletion ⑨ Making a call Calling screen ① Activated call sign ② Stand-by call sign ③...
Page 8: Receiving A Call
• Making a general calls (Option) 1. After holding the handset or pushing the speaker phone button, press (general) on the screen of the phone. 2. After entering the other party’s number, press (Call). Ex) 01022223333 3. While hearing the dial tone, the connecting call screen will be displayed. 4.
Page 9 • To get the phone of household 1. The household telephone with bell sound is indicated. 2. To call, press (call) or To reject, press (rejection). 3. To end the call, press (end). ※ In a household, video telephone can be used through the camera of a guard station but in a guard station, the screen of a household is not shown.
Page 10 •Call history 1. You can call again to him or her by pressing in the middle of call history. Call history screen 2. If you press the recorded call list in a short time to select, additional function such as checking information of recent call list, phone call, an address list can be used.
Page 11: Address List
3. If you press the recorded call list in a long time to select, call, number edit, adding to address list, recent call list, delete function in a call list can be used. Saved call record screen 2 • Address list screen 1.
Page 12: Favorites
2. After pressing , it can be added in favorites. 3. After pressing , you can have a conversation. ② ③ Saved address list screen • Favorites 1. Through the address list, the saved list can be checked then press to make a call.
Page 13 2. After pressing , you can make favorites or cancel it. 3. You can make a call by clicking. Favorites screen 2...
Page 14: Emergency Log
6. Emergency log • Emergency occurence You can check occurred household building and number and time of emergency. In a household, you can also check the process like emergency occurrence Stop Control of return. If you press the receipt button, emergency-received information can send to the server.
Page 15 7. Checking visitors Through the camera installed in lobby, you can check visitors’ images and pictures taken from CCTV in a household. • Checking saved pictures 1. Through the screen of checking visitors, pictures taken in a lobby, CCTV is distinguished and saved date and time can be checked.
Page 16 • Deletion of the saved images 1. Press the picture ①(Viewing menu) or press the picture you want to select more than 2 minutes, it will be converted into [selection mode]. 2. Select a picture you want or select all pictures with 3.
Page 17: Checking Cctv
8. Checking CCTV Installed CCTV images can be checked and saved. Also, 4 CCTV screens can be checked at the same time ① CCTV image screen ② Saving screen ③ DVR Selection ④ Channel list ⑤ Favorites ⑥ Selection list ⑦...
Page 18 • Checking the information of CCTV 1. If you press ③(toggle), you can check the designated name and DVR of CCTV like ①. ① Information of CCTV ② Move of screen ③ Checking the information of CCTV ④ Going back CCTV Multiview ※...
Page 19 • COMMAX user option Set the COMMAX connection and management 1. Password change You can change the password to off emergency situation and go out mode.
Page 20 • Connection to COMMAX and management It sets up the configuration of COMMAX connection and management for telephone, home control, security function, etc. but public access to set up the configuration is prohibited(the manager of installation only). This product is not working if you do not enter correct value.
Page 21 ☞ As you press the confirm button, the selected bell sound is set. 4. To set the brightness of screen ☞ Press the brightness. ☞ Brightness window is marked in a screen. ☞ Adjust the volume by moving the stick. ☞...
Page 22: Date And Time
• Date and time Able to set the date and time. 1. To set the date and time automatically ☞ Check the automation. ☞ Time server(NTP) and synchronization interval icon are activated. ☞ After pressing time server(NTP), enter the time server. If it is connected with entered time server well, it is changed to the current time.
Page 23: Wiring
10. Wiring. ① power switch : On/ Off ② Local port : Local network connectable ③ Consol Port : Consol Debug 1 : TX, 2 : GND, 3 : RX, 4 : VCC ④ CCTV : CCTV Image check and saving function 1 : VIDEO_OUT, 2 : GND ⑤...
Page 24: Caution In Use
1. Turn on the power switch. 2. Please contact your local agent for product maintenance when you have a problem in use of CDS-70M 3. For your safety, power switch with a safety device must be used in your building.
Page 25 Memo...
Page 26 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. Tel. : +82-31-7393-540~550 Fax. : +82-31-745-2133 Web site : www.commax.com PM0470M00010 Printed In Korea / 2012.01.104...
