PMC BiSerial-III-HW2
Eng Kit–PMC BiSerial-III
Note: The Engineering Kit is strongly recommended for first time PMC BiSerial-III purchases.
Schematics
Schematics are provided as part of the engineering kit for customer reference only. This
information was current at the time the printed circuit board was last revised. This
revision letter is shown on the front of this manual as "Corresponding Hardware
Revision." This information is not necessarily current or complete manufacturing data,
nor is it part of the product specification.
All information provided is Copyright Dynamic Engineering
PMC Module with up to 32 serial channels, 34 bit parallel port
(overlaps with serial channels) RS-485 I/O. 32-bit data interface
HDEterm68 - 68 position screw terminal adapter
http://www.dyneng.com/HDEterm68.html
HDEcabl68 - 68 I/O twisted pair cable
http://www.dyneng.com/HDEcabl68.html
Technical Documentation,
1. PMC BiSerial-III Schematic
2. PMC BiSerial-III-HW2 Driver software and user
application.
Data sheet reprints are available from the manufacturer's web
site
Embedded Solutions
Page 50 of 50
