PMC PCI Pn1 Interface Pin Assignment

The figure below gives the pin assignments for the PMC Module PCI Pn1 Interface on
the PMC BiSerial-III. See the User Manual for your carrier board for more information.
Unused pins may be assigned by the specification and not needed by this design.
GND
BUSMODE1#
GND -
CLK
GND -
AD28-
AD25-
GND -
AD22-
AD19
FRAME#-
GND
DEVSEL#
GND
PAR
AD12-
AD9-
GND -
AD6-
AD4
AD2-
GND
FIGURE 26
-12V(unused)
INTA#
+5V
GND
+5V
AD31
AD27
GND
C/BE3#
AD21
+5V
AD17
GND
IRDY#
+5V
LOCK#
GND
AD15
AD11
+5V
C/BE0#
AD5
GND
AD3
AD1
+5V
Embedded Solutions
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19 20
21 22
23 24
25 26
27 28
29 30
31 32
33 34
35 36
37 38
39 40
41 42
43 44
45 46
47 48
49 50
51 52
53 54
55 56
57 58
59 60
61 62
63 64
PMC BISERIAL-III PN1 INTERFACE
