Address Map
BIS3_BASE
BIS3_ID
BIS3_START_SET
BIS3_START_CLR
BIS3_START_RDBK
BIS3_IO_DATA
BIS3_IO_DIR
BIS3_IO_TERM
BIS3_IO_MUX
BIS3_IO_UCNTL
BIS3_STAT_FIFO
BIS3_PLL_CMD
BIS3_PLL_RDBK
BIS3_SM_CNTL_0
BIS3_SM_CNTL_1
BIS3_SM_CNTL_2
BIS3_SM_CNTL_3
BIS3_SM_CNTL_4
BIS3_SM_CNTL_5
BIS3_SM_CNTL_6
BIS3_SM_CNTL_7
BIS3_SDLC_CNTL_0
BIS3_ASYNC_CNTL_0 0x0060
BIS3_ASYNC_CNTL_1 0x0068
BIS3_SDLC_CNTL_1
BIS3_ASYNC_CNTL_2 0x0060
BIS3_ASYNC_CNTL_3 0x0068
BIS3_SDLC_CNTL_2
BIS3_ASYNC_CNTL_4 0x0070
BIS3_ASYNC_CNTL_5 0x0078
BIS3_SDLC_CNTL_3
BIS3_ASYNC_CNTL_6 0x0080
BIS3_ASYNC_CNTL_7 0x0088
BIS3_SDLC_CNTL_4
BIS3_ASYNC_CNTL_8 0x00A0
BIS3_ASYNC_CNTL_9 0x00A8
BIS3_SDLC_CNTL_5
BIS3_ASYNC_CNTL_10 0x00B0
BIS3_ASYNC_CNTL_11 0x00B8
0x0000 0 Base control register
0x0004 1 ID register
0x0008 2 Start-bit set register
0x000C 3 Start-bit clear register
0x0008 2 Start-bit read-back
0x0010 4 Data register 31 - 0
0x0014 5 Direction register 31 - 0
0x0018 6 Termination register 31 - 0
0x001C 6 Mux register 31 - 0
0x0020 8 Upper control register 33, 32
0x0024 9 User switch value
0x0028 10 PLL control register and read-back of PLL data
0x002C 11 PLL control register read-back
0x0040 16 Chan 0 state-machine control read-write port
0x0044 17 Chan 1 state-machine control read-write port
0x0048 18 Chan 2 state-machine control read-write port
0x004C 19 Chan 3 state-machine control read-write port
0x0050 20 Chan 4 state-machine control read-write port
0x0054 21 Chan 5 state-machine control read-write port
0x0058 22 Chan 6 state-machine control read-write port
0x005C 23 Chan 7 state-machine control read-write port
0x0060 24 Chan 8 SDLC control read-write port
24 Chan 8 asynchronous control read-write port
26 Chan 10 asynchronous control read-write port
0x0060 28 Chan 12 SDLC control read-write port
28 Chan 12 asynchronous control read-write port
30 Chan 14 asynchronous control read-write port
0x0070 32 Chan 16 SDLC control read-write port
32 Chan 16 asynchronous control read-write port
34 Chan 18 asynchronous control read-write port
0x0080 36 Chan 20 SDLC control read-write port
36 Chan 20 asynchronous control read-write port
38 Chan 22 asynchronous control read-write port
0x00A0 40 Chan 24 SDLC control read-write port
40 Chan 24 asynchronous control read-write port
42 Chan 26 asynchronous control read-write port
0x00B0 44 Chan 28 SDLC control read-write port
44 Chan 28 asynchronous control read-write port
46 Chan 30 asynchronous control read-write port
