Mode Resource Mapping

Mode-Dependent I/O Mapping for a Four-Channel Block
I/O line SDLC Mode
I/O 0 Transmit Data
I/O 1 Receive Data
I/O 2 Transmit Clock
I/O 3 Receive Clock
Mode-Dependent Interrupt Mapping for a Four-Channel Block
Int line SDLC Mode
Int 0 Transmit Interrupt
Int 1 Receive Interrupt
Int 2 unused
Int 3 unused
Mode-Dependent Dual-Port RAM Mapping for a Four-Channel Block
DPR SDLC Mode
DPR 0 Lo Transmit Buffer Transmit 0 Buffer
DPR 1 Hi Transmit Buffer Receive 0 Buffer
DPR 2 Lo Receive Buffer Transmit 1 Buffer
DPR 3 Hi Receive Buffer
Note that all number designations are relative to the number of the first channel in the
referenced channel block.
Async Mode
Transmit Data 0
Receive Data 0
Transmit Data 1
Receive Data 1
Async Mode
Transmit 0 Interrupt
Receive 0 Interrupt
Transmit 1 Interrupt
Receive 1 Interrupt
Async Mode
Receive 1 Buffer
Embedded Solutions
HW1 Mode
Transmit/Receive Data 0
Transmit/Receive Data 1
Transmit/Receive Data 2
Transmit/Receive Data 3
HW1 Mode
Channel 0 Interrupt
Channel 1 Interrupt
Channel 2 Interrupt
Channel 3 Interrupt
HW1 Mode
Channel 0 Buffer
Channel 1 Buffer
Channel 2 Buffer
Channel 3 Buffer
