PARAMETER
Phase-neutral voltage
Phase-phase voltage
Current
Frequency
Active power
Reactive power L
Reactive power C
Apparent power
Power factor
Cos ϕ
Maximum demand
Neutral current
Voltage THD
Current THD
kWh (consumption and generation)
kvarh.L (consumption and generation)
kvarh.C (consumption and generation)
kVAh (consumption and generation)
Harmonic content (V and A) *
Temperature
( • ) Available through display and communications.
( •• ) Only available through communications.
( * ) Harmonic content in HAR model.

1.4 Other features

• A small sized instrument with a 85x52x70mm (3 steps).
• Measurement in true effective value (TRMS).
• Instant, maximum, minimum values for each parameter.
• Energy measurer function.
• 1 GW·h counter in consumed energy.
• 100 MW·h counter in generated energy.
• Backlit LCD display.
• Built in RS485 communications (Modbus RTU®).
• Temperature probe built in the equipment.

1.5 Available models

CODE REFERENCE
M52000 CVM-MINI-Shunt
M52010 CVM-MINI-ITF
M52021 CVM-MINI-ITF-RS485-C2
M52031 CVM-MINI-ITF-HAR-RS485-C2
M52022 CVM-MINI-ITF-Plus-RS485-C2
UNIT
V f-n
V f-f
A
Hz
kW
kvarL
kvarC
kVA
PF
ϕ
Cos
Pd
I
N
% THD - V
% THD - A
W·h
W·h
W·h
W·h
%
ºC
Page 4 of 26
L1 L2 L3 III
• • •
• • •
• • • ••
•
• • • •
• • • •
• • • •
• • • •
• • • •
•
• • • •
•
• • •
• • •
•
•
•
•
th
• • • 15
•
Ci r c
u t o r
UER1 . 0 0
