4.1.7.1 Impulse per n KW·h or Kvar·h consumed or generated
In order to generate an impulse for consumed n kW·h, the energy meter to be
used has to be selected:
PARAMETER
Active energy III
Inductive reactive energy III
Capacitive reactive energy III
Apparent energy III
Active energy generated III
Inductive reactive energy generated III
Capacitive reactive energy generated III
Apparent energy generated III
Once the energy code has been selected and entered using the
watts·time per impulse is entered or as a default, kilowatts·time per impulse.
For entering the watts·time rate per impulse, repeatedly press the
increasing the value of the digit which is flashing at the time.
When the required value is on the screen, move on to the following digit by
pressing , to allow the remaining values to be changed.
min
When the last digit has been changed, press
digit, allowing the previously set values to be changed again. To enter the data
and access the next setting step, press

4.1.7.2 Alarm condition

In order to link an alarm condition to an energy parameter, the code for the
selected parameter has to be entered. A list of electrical parameters and their
codes is shown below.
.
Ou t 1
Pu l s
0 0 0 . 0 0 0
Figure 48. Watts / impulse
Page 16 of 26
SYMBOL CODE
kW·h III 31
KvarL·h III 32
KvarC·h III 33
kVA·h III 44
kW·h III (-) 45
KvarL·h III (-) 46
KvarC·h III (-) 47
48
kVA·h III (-)
to move back to the first
min
key, the
key
max
