6 TECHNICAL DATA

Housing
Protection class
Power supply:
-Battery
-Solar panel
-Switched Output
-Buffer-battery
-Mains operation
Power consumption battery (COM2 and COM3 switch off):
Temperature range
Temperature Display : -20...+60°C (for reading)
Storage Temperature : -40...+85°C
Humidity
Analogue Measurement:
-A/D-Converter
-Accuracy analogue : ±0,1% of measuring span of the sensors, without long term drift
-Internal Channels
-Input resistance internal channels :
-Factory calibration 40mV-Input series resistance :
Additional analogue channels (applies for 9.1756.x0.100):
: stainless steel
: IP 65
: 12V 7Ah (lead acid valve regulated VRLA), voltage is monitored
: 12V 20W max
: 12V 1.5A max. (e.g. for supplying a GSM-Modem)
: 3V 0.56Ah, buffering data memory and real time clock
: monitoring status of mains(On/Off)
Out all versions:
91756.x0.x00:
9.1756.x0.001:
approx. 12mA
max. 1mA
: -30...+60°C
: up to 100% RH, non-condensing
: 24 Bit theoretical resolution with fully differential inputs
: 6
1 Voltage for radiation sensor
1 Voltage for humidity
1 Voltage for air pressure
1 Current
2 Temperature Pt100
0...40mV 100kΩ
0...1V 100kΩ
0...5V 200kΩ
0...20mA 120Ω
12Vdc 0.2A, powered by 24Vac output (e.g.
permanent supply for fan)
In: 230Vac 100VA 0.5A
Out: 24Vac 90VA (e.g. heating of sensors)
16Vac 10VA (datalogger and sensors)
In: 230Vac 260VA 1.25A 135°C thermal trip switch
Out: 26Vac 220VA (e.g. heating of sensors)
24Vac 24VA
16Vac 10VA (datalogger and sensors)
(Display active without Sensors)
(Display off)
(0...40mV)
(0...1V)
(0...5V)
(0...20mA)
(-40...70°C)
100Ω
