2.1.9

Setting Digital Input

The digital input „Event / Length of time" (Sensor 10) can be configured for two possibilities with the
Jumper P2:
Jumperposition P2
2
3
* The corresponding switching levels are listed in the technical data (see chap. 6)
** Note that with jumper in position 3 the logic level is reversed by the electronic.
The jumper P2 is situated 2 cm above clamp 13 (see Figure 12). To change or check the position it
is necessary to remove the front plate (see Figure 5, ref. to chap. 2.1.8).
Logic *
3.3V(5V TTL)
1V
Table 2: Jumper for digital input
Figure 12: Jumper for Digital Input
16 - 56
Inverse Level
No Pull-up Resistor 100kΩ to 3.3V
Yes **
Miscellaneous
Resistor > 1kΩ
