21. SWITCH OUTPUT TIMER:
*PROG-Timer: X
programmed
Display of the programmed timers for the connection of a consumer load (for ex. GSM-Modem,
refer to chap.3.2.6).
Serial command: "FS" (ref. to chap.5.5)
22. A/D-Converter State:
A/D: OK
State for service purposes only:
OK (A/D converter in order)
Err (A/D converter defect)
23. STATE EEPROM:
Estado EEPROM
Usuario:OK DL:OK
State of the EEPROM memory (parameter memory for user-settings and calibration values).
In case "OK" is not displayed here, the instrument might be defect.
24. BAUD RATE (COM1) / SD-Card:
* COM 1:Command
9600 Bd 8N1
RS232
No SD-Card in the slot
Display of the settings of COM1
Setting options:
300, 600, 1200, 2400, 4800,
9600, 19200, 38400, 57600
and 115200 Bd
8 data bits, no (none) parity,
1 stop bit, RS232 or RS485-4Wire
Serial commands: "CC1", "CR1"
(ref. to chap.5.5)
X= 1,2,3,4,5,6
*PROG-Timer:
xxxxxxxx 04.2008
SD-Card in the slot of the Datalogger
(Example, line 2 and 3 are specific for each SD-Card)
Display of the so-called "Card Identification
Register"(CID) of the SD-Card in the slot. The data of
the CID is necessary to differ the cards, since the label
on the card is normally of no relevance. Unfortunately
not all SD-Cards works with the datalogger (see chap.
5.2 for tested SD-Cards).
Line 2 : MID, OID, PNM, PRV of the CID
Line 3 : Product serial number (x) and manufacturing
date (month and year)
27 - 56
deactivated
SD-Card:
2 TM SD02G 3.2
021579/06/09
