13. SENSOR 10 Event / Length of time:
* Event/Length :
NNN.N
Event
L:N
Line 2:
Line 3:
Measuring range:
Resolution:
Serial command: "LS" and "LT" (ref. to chap.5.5)
Remark:
To setting up or check the logic level (3.3V or 1V) see chap. 2.1.8.
From here will displayed the instantaneous data of serial sensors if configured (e.g. Sensor-
interface or Sonic-windsensor). See following display 16 for adjustment and refer to chap. 3.2.5 for
additional information.
14. SENSOR CONFIGURATION:
*Channel config:
xxxxx xxxxx
Channels: 10+YY
Sensor 1...10
Display of the configured internal measuring channel („1"→ switched on). Measuring channels
which are not configured („0"→ switched off) are marked by bars (for ex. „---.-") in the display and in
the data output.
The first digit (from the left side) means the 1. measuring value of the sensor (wind speed) the last
one means sensor 10 (state/length).
For more information to change the sensor configuration ref. to chap. 3.2.3
Serial command: "KK" (ref. to chap.5.5)
Display of the instantaneously measured digital state input:
Mode Event: Level active (-> 1) / non-active (-> 0)
Mode Length: Length of time in minutes during the current day
Display and input of the mode of the digital state input (Event or Length) and
the active logic (L:0 -> low active logic, L:1 -> high active logic)
0,1 (Mode: Event) or 0 .... 9999 min (Mode : Length)
6 seconds (Mode : Length)
x = "0" Sensor switched off
x = "1" Sensor switched on
YY= 00 to ??: Number of external channels
24 - 56
021579/06/09
