25. BAUD RATE (COM2)
* COM 2:SIF001
9600 Bd 8N1
RS232
Display of the settings of the serial interface COM2.
Setting options are the same like COM1 (see above).
In the first line the actual setting of the mode is displayed (here "SIF001", see display 16: SERIAL
INTERFACES MODE for adjustment).
Serial commands: "CC2","CR2" (ref. to chap.5.5)
26. BAUD RATE (COM3)
* COM 3:Sonic
9600 Bd 8N1
485-2Wire
Display of the settings of the serial interface COM3.
Setting options are the same like COM1 (see above). except for fixed serial operation mode
(always RS485-2Wire).
Serial command: "CC3" (ref. to chap.5.5)
27. OPERATION MODE:
*Mode:
Normal
Display of the selected mode:
„Normal":
„ Maintenance ":
Remark:
The maintenance mode is stopped automatically when the display is switched off!
normal mode
Maintenance mode (Measuring values are not stored in the memory)
28 - 56 021579/06/09
