„DE"<DdMoYyHhMi>
"de" "<d><m><y><h><m>
"EP"
"LL"
"MM"
"mm"
"DD"
"DT"<1..31>
"DM"<1..12>
"DJ"<0..99>
"ZZ"
"ZH"<0..23>
"ZM" <0..59>
„ZS" <0..59>
"XX"
„XXn"<AAAAA>
„LM"<500..900>
„LN"<500..900>
"WV"<0..3>
"WW"<0,1>
"WD"<0..2>
„NS"<1,2>
"NT"<0,1>
„LS"<0,1>
„LT"<0,1>
„SK"<n>' '<NN.NNNN>
"KK"<01..10>' '<0,1>
"FF"
"FS"<1..6><HH><MM><LL>
Output of stored extreme data from a specific time
Description of parameters: refer to chap. 5.5.1
Output of EEPROM-data (parameter memory) for service purposes
Logger status:
Output station name, date and time , state of the AD-transducer,
sensor configuration, measuring and storing rates, voltage of the
accumulator, state of power supply, radiation constant, EEPROM-
status, operation mode, contact output-Timer, last DCF-
synchronisation time and appropriate logger time
Instant. measuring values: output with sensor identification (multiline)
Instantaneous measuring values: output as single-line data record
(sequence as in the display output)
Output Logger-date
Entering day: Setting of day for the logger-clock (*)
Response: entered day, logger date
Entering month: setting of month for the logger-clock (*)
Response: entered month, logger date
Entering year: setting of year for logger-clock (*)
Response: entered year, logger date
output logger-time
Entering hour: entering of hour for the logger-clock (*)
Response: entered hour, logger-time
Entering minute: entering of minute for the logger-clock (*).
The second is set to zero.
Response: entered minute, logger-time
Entering second: setting of second for the logger-clock. (*)
Response: entered second, logger time
Output of the station name, instrument type, and software-version.
Entering station name
Enter of the lower measuring range in hPa of the air pressure sensor
Enter of the higher measuring range in hPa of the air pressure sensor
Wind speed sensor type
(0:COMx, 1:Compact, 2:Classic, 3:FirstClass)
Wind speed sensor current flow test (0:Off)
Wind direction sensor type (0:COMx, 1:5-/8-Bit, 2:10-Bit)
Precipitation sensor type resolution (0.1mm / 0.2mm)
Precipitation sensor current flow test (0:Off)
Digital input mode: Event(0) or Length(1)
Digital input logic: active logic low (0) or active logic high (1)
Enter radiation constant n (n=1...5)
Example: STX „SK1 12.42" ETX (set constant 1 to 12.42)
Entering sensor configuration of a internal sensor
<01..10> sensor number
<0,1> 0 -> switch off 1 -> switch on
Example: STX "KK02 1" ETX (switch on sensor 2)
Output of all switch-output timers
Setting of a switch output-timer:
<HH> starting hour, <MM> starting minute, <LL> power-on time in
minutes
Ex.: STX "FS2083005" ETX (timer 2, start at 08:30 h, time: 5
minutes)
44 - 56
<1..6> timer number,
