1 MODELS

Order-No.
9.1756.00.000
9.1756.10.000
9.1756.00.100
9.1756.10.100
9.1756.00.001
9.1756.10.001

2 CONSTRUCTION OF THE DATALOGGER

Prim. 230V 0,43A 50/60Hz
Prim.Sicherung 0,5 AT
Sek.: 1 x 24V 3,75A 100 VA
Sek. Sicherung 1 x 4,0 AT
Sek.: 1 x 16V 0,6A
Sek. Sicherung 1 x 0,8 AT
BV 9951
230V
PE 0 0
0,5AT
Si
230VAC
mains
Sensor-Interface
nach VDE 0551
24V 16V
0
4,0 AT 0,8 AT
Si Si
Clamps
1 ... 56 (bottom side)
Figure 1: Connections
Transformer
no
yes
no
DLx MET
Akku
DCF77 Clamps
57 ... 68
4 - 56
Case version
100VA
260VA
Grounding
Earth
B
A
B
A
B
A
SD-Card slot
USB
COM 1
COM 2 + 3
021579/06/09
