3.2.8 DCF77 SYNCHRONIZATION

*DCF: 1 !!.!!.!!
ffff n !!:!!:!!
!!.!!.!! !!:!! 0
DCF-antenna on
This display serves for switching on and off the DCF-antenna, indicates the last time of
synchronization (third line) and the manual start of synchronization.
When the DCF-antenna is active, it tries to receive a time telegram at night from 01:30 h (max. 10
minutes) because of the better reception. This time telegram is sent during standard time as CET
("Central European Time", CET=UTC+1h), and during daylight saving time as CEST ("Central
European Summer Time", CEST=UTC+2h). This time telegram is converted in UTC, and the
internal clock is synchronized.
In the edit mode the antenna can be activated and deactivated. Additionally in the third line the last
synchronised DCF77-Time is given out:
*DCF: 1
30.04.09 03:33 s
With active DCF-antenna, and sufficient reception, when you wait approx. 2 minutes or longer, the
DCF time telegram is displayed, and the internal clock is synchronized (provided that no error
occurs).
Example: Reception of a time telegram (year not yet received)
*DCF: 1 30.04.!!
ffff n 09:06:52
When the minute mark has been received, the seconds are set to zero
Second 28: reception minute
Second 35: reception hour
Second 41: reception day
Second 49: reception month
Second 57: reception year
*DCF77: 0
!!.!!.!! !!:!! 0
DCF-antenna off
s = 0 CET/standard time
s = 1 CEST/daylight saving time
ffff = Error display in the hexadecimal (0 means "no error")
n = 0...9 display of the received second pulses
