Levelling: 211 or 311 units

1
x2
x2
2
3
4
x2
x2
We built our units by level. That means
the pan is in accordance with the frame. Once you
have levelled the frame, the pan should be levelled
also.
The levelling is done exclusively by adjusting the
foots of the unit. Proceed as follows:
Step 1
Units are delivered with the foots fully screwed.
Before starting to level the unit unscrew each foot
of two turns.
Step 2
Open side panel and level unity by adjusting both
foots.
Step 3
3. Open the lid and check pan level from the right to
the left. Adjust if necessary by turning the left front
foot.
Step 4
Check pan level from the front to the rear.
Adjust the left back foot if necessary.
- 11 -
Pict. 1
Pict. 2
Pict. 3
Pict. 4
