Rational VarioCooking Center 112 Installation Manual page 25

Installation Options
1
2
3
4
Set for base frame
Units ordered with option base frame will be deliv-
ered with standard legs. The mounting of the base
frame must be done on site.
112
211/311
Mounting instructions is supplied with the base
frame. For levelling of the unit refer to the chapter
levelling.
Article number
Models 112
Models 211/311
Base frame mounting dimensions
Models High under
unit
112 50 mm
211/311 65 mm
Set for wall mounting
Assembling of these set must be done on site.
Mounting instructions is supplied with the wall
mounting set. For levelling of the unit refer to the
chapter levelling.
Wall mounting set article number
Models 211/311 only
Heightening kit 100 mm for foots/Casters
The mounting between the frame and the foot or
casters has to be done on site.
Article number
All models
(Made of 4 pieces)
- 25 -
12.00.706
12.00.704
Max. high of base
frame (
recommended
120 mm
+/- 5mm
105 mm
+/- 5mm
12.00.751
of the kit 100
60.72.341
Pict. 1
Pict. 2
.)
Pict. 3
Pict. 4
mm
v08
