3.5.4 HART Menu

1 Device Setup
2 Level
view level in %
3 Current
view level in mA
4 Date
displays date entered in
Calibration>Date/Time/initials
23
1 Enter Password
password set at
factory = 1
2 Calibration
3 Basic Setup
4 Advanced Setup
5 Review
review all existing
parameters
48-618 ES/EZ Modulevel Displacer Level Transmitter (Top Hat Assembly Design)
1 Set Points
2 Damping
3 Fault State
select 3.6 mA–down
button
or 22 mA–up button
4 Date/Time/Initials
enter this info as
customer record of
recalibration
5 Loop Test
1 Tag
enter tag # of unit
2 Descriptor
16 place customer
descriptor for unit
3 Message
32 place customer
message
4 Final Assembly Number
5 Poll Adr
value is 0 unless for
multidrop use
