TRANSMITTER TYPE & MOUNTING
E Electronic Integral Mount
G Electronic Remote Mount
R Electronic High-temp Integral Mount
TRANSMITTER OUTPUT
Z 4-20 mA only (Analog)
S 4-20 mA with HART (Digital)
ΠHART communicator sold separately
TRANSMITTER CONFIGURATION AND ACCESSORIES
Integral Mount
Fourth Digit 2 only
Eighth Digit E only
+300° F max.
Remote Mount
Fourth Digit 8 only
Eighth Digit G only
+400° F max.
HT-Integral Mount
Fourth Digit 8 only
Eighth Digit R only
+500° F max.
Remote Mount
Fourth Digit 8 only
Eighth Digit G only
+500° F max.
Last 3 Digits of Model Number
48-618 ES/EZ Modulevel Displacer Level Transmitter (Top Hat Assembly Design)
24 VDC, 120 VAC or 240 VAC
Œ
24 VDC only
Code Display Input Voltage
A None
B None
C None
D None
G Analog
I Analog
L Analog
N Analog
Ž
J Digital
Ž
9 Digital
H None
2 None
3 None
K Analog
5 Analog
6 Analog
Ž
7 Digital
Q None
W None
T Analog
X Analog
Ž
4 Digital
Ž
Z Digital
Q None
R None
S None
T Analog
U Analog
V Analog
4 Digital
 120 & 240 VAC available on Analog unit only (ninth digit Z)
Ž Digital meter available on Digital Hart compatible unit only (ninth digit S)
REMOTE CONNECTING CABLE
Up to +400° F, specify cable 037-3218-0XX, where last two digits are
cable length in feet from 1-75 feet.
Up to +500° F, specify cable 037-3220-0XX, where last two digits are
cable length in feet from 1-75 feet.
Agency Approval
24 VDC EP – FM, CSA, CENELEC

120 VAC EP – FM, CSA

240 VAC EP – FM, CSA
24 VDC IS/NI – FM, CSA, CENELEC
24 VDC EP – FM, CSA, CENELEC
24 VDC IS/NI – FM, CSA, CENELEC

120 VAC EP – FM, CSA

240 VAC EP – FM, CSA
24 VDC IS/NI – FM, CSA
24 VDC EP – FM, CSA, CENELEC
24 VDC EP – FM, CSA

120 VAC EP – FM, CSA

240 VAC EP – FM, CSA
24 VDC EP – FM, CSA

120 VAC EP – FM, CSA

240 VAC EP – FM, CSA
24 VDC EP – FM, CSA
24 VDC IS/NI – FM, CSA, CENELEC
24 VDC EP – FM, CSA, CENELEC
24 VDC IS/NI – FM, CSA, CENELEC
24 VDC EP – FM, CSA, CENELEC
24 VDC EP – FM, CSA, CENELEC
24 VDC IS/NI – FM, CSA
24 VDC EP – FM, CSA

120 VAC EP – FM, CSA

240 VAC EP – FM, CSA
24 VDC EP – FM, CSA

120 VAC EP – FM, CSA

240 VAC EP – FM, CSA
24 VDC EP – FM, CSA
