4.6.2 CSA (Canadian Standards Association)

Model
XE5X-XXXX
with transmitter codes:
E5X-XXXX
with transmitter codes:
E5X-XXXX
with transmitter codes:
4.6.3 ATEX (European Directive for Explosion Protection
Model
ATEX
Œ
Field wiring must be installed in conduit.

If IS or NI CSA nameplate is required, this must be specified at time
of order placement.
Ž
ATEX EP approval available on standard 900#, 1500#, and 2500#
models. 150#, 300#, and #600 models require modification for ATEX
EP approval and must be "X'd" for a heavy wall e-tube.

Entity parameters for ATEX EEx ia installation:
Ci = 5 nF, Li = 800 H
Ui = 28.4 V, Pi = 0.67 W or
Ui = 26.4 V, Li = 99 mA, Pi = 0.66 W
48-618 ES/EZ Modulevel Displacer Level Transmitter (Top Hat Assembly Design)
EZA, B, C, E, F, G, L, N
ESA, E, F, G, 7, 9
GZH, K, Q, R, S, T, U, V, 2, 3, 5, 6
GSH, K, Q, T, 4, 7
RZW, X
RSW, X, 4
EZD, H, I, K
ESD, H, I, J, K, 8
GZH, K, Q, T 
GSH, K, Q, T, 4, 7 
RZQ, T
RSQ, T, Z
EZD, H, I, K
ESD, H, I, J, K, 8
GZH, K, Q, T 
GSH, K, Q, T, 4, 7 
RZQ, T
RSQ, T, Z
XEXX-XXXX, EXX-XXXX with transmitter codes
EZA, E, F, G
ESA, E, F, G, 7, 9
RZW, X
RSW, X, 4
EXX-XXXX with transmitter codes
ESD, I, H, K
RSQ, T
EXX-XXXX with transmitter codes
ESJ, 8
RSZ
Approval
Explosion Proof
Class I, Div. 1; Groups B, C, D
Class II, Div. 1; Groups E, F, G
Class III, Type 4X
Intrinsically Safe
Class I, Div. 1; Groups A, B, C, D
Class II, Div. 1; Groups E, F, G
Class III, Type 4X
Entity
Non-Incendive
suitable for:
Class I, Div. 2; Groups A, B, C, D
Class II, Div. 2; Groups E, F, G
Class III, Type 4X
Approval
Ž
Explosion Proof
ATEX Ex II 1/2 G EEx d IIC T6

Intrinsically Safe
ATEX Ex II 1 G EEx ia IIC T6

Intrinsically Safe
ATEX Ex II 1 G EEx ia IIC T5
These units have been tested to EN 50081-2
and EN 50082-2 and are in compliance with
the EMC Directive 89/336/EEC.
