Magnetrol ES Modulevel Installation And Operating Manual page 39

12
Displacer
Low Pressure
0.5/1.0
14" 89-6125-001
32" 89-6125-002
48" 89-6125-003
60" 89-6125-004
72" 89-6125-005
84" 89-6125-006
96" 89-6125-007
108" 89-6125-008
120" 89-6125-009
13
Cotter pins
All Units
48-618 ES/EZ Modulevel Displacer Level Transmitter (Top Hat Assembly Design)
Transmitter P.C. Board
1
Assembly and Bracket
Housing Base
4
and Cover
6
Housing O-Rings
7
Enclosing Tube
8
Gasket
9
Flange
or
Flange
Assembly
High Pressure
2.0 1.0
89-6126-001 89-6125-010
89-6126-002 89-6125-011
89-6126-003 89-6125-012
89-6126-004 89-6125-013
89-6126-005 n/a
89-6126-006 n/a
89-6126-007 n/a
89-6126-008 n/a
89-6126-009 n/a
10-5203-001
LVDT
Core Stem
10
LVDT
2
Assembly
Junction Box
5
Meter
3
Only
11
Range Spring
13
Cotter
Pins
12
Displacer
36
