Planning Installation

Antenna Mounting Hole Pattern

The mounting holes must be in the exact same place as shown in the diagram below.
4-ø13 Holes
247.5mm (9.74")
ø445mm (17.5")
Figure: Antenna Mounting Hole Pattern
