Planning Installation; Installation Kit - Intellian v85NX Installation & Operation User Manual

Planning Installation

Installation Kit

Before beginning installation, make sure you have all the included components.
Description
Antenna Control Unit (ACU)
Quick Installation Guide (QIG)
RF Hazard Sticker
Mounting Template
ACU Side Bracket (Rack Type)
Flat Head Screw
USB Cable (A-A)
AC Power Cord (CEEE7/7)
RG-6 RF Cable
Modem Interface Cable
(For iDirect Modem)
Ethernet Cable (RJ45/LAN)
Wi-Fi Dongle
Hex Bolt
Flat Washer
Spring Washer
Hex Head Wrench Bolt
Spring Washer and Flat Washer
Sems Bolt
Radome Door Key
Waterproof Foam
Q'ty Size
1 431x350x44.3mm
1
1
1
2
10 M4x12L
1 1.8m
1 1.5m
2 1m
1 1.5m
2 1m
1
5 M12x80L
5 M12
5 M12
5 M6x40L
5 M6
2 M4x8L
2
1
13
Planning Installation
Remarks
Antenna Control Unit (ACU)
Radiation Safety Distance (15m) Label
ACU to 19inch Rack
Bolt Kit for Rack Type Mount Bracket
ACU (Front Panel) to PC
ACU Power (220V)
ACU to Modem
ACU to Modem (iDirect Modem)
ACU to PC/Intellian M&C
Bolt Kit for Antenna - Deck Assembly
(1 spare set included)
Bolt Kit for Radome Assembly
1 Door key & 1 Spare key
X-shape Cable Hole Type
